7-2 Main Parts List
Samsung Electronics 7-3
Ref. No. Parts No. Description/Specification Q'ty Remarks
M 41 DE26-20152A TRANS-L.V;SLV-105E,230V,50HZ,AC17V/3V 1
M 42 DE60-60025A PIN-FOOT;PP-JI350,BLK 4
M 43 DE61-40065A FOOT;PP,BLK,T2x22x17mm 4
M 44 DE63-90062C CUSHION-H.V.T;NR,T18,W30,L50,CK95 1
M 45 DE80-10001D BASE-PLATE;SGCC,T0.8,W345,L565,-,CK95 1
M 46 DE31-10170A MOTOR-DRIVE;M2LJ24Z702,ST-16F,220/240V,2.5 1
M 47 DE71-60382A COVER-CEILING;MICASHEET,T0.5,70,133 1
M 48 DE73-90027A FERRITE-CORE;NI-ZN,T13.8,W21.0,L28.0,BNF-14 1
M 49 DE72-60005A GUIDE-AIR;SECC1-P,T0.5,210,225 1
M 50 DE32-10013A SENSOR-THERMISTOR;PT-312-K2 1
M 51 DE71-60459A COVER-ADIABATIC-L;SECC,T0.6,W252,L300,-,CK95 1
M 52 DE62-90103A ADIABATIC-LEFT;SUPERFINE INSULATION,T7,W250,L 1
M 53 DE39-40409A WIRE HARNESS-E;230V50HZ,M9G45,CTW 1
M 54 DE39-40759A WIRE HARNESS-B;230V50HZ,CK95 1
M 55 DE47-20009A THERMOSTAT;PW2N-520PB,160/60,250V/7.5A,M 1
M 56 DE92-40215A ASSY DOOR;CK95,WHT 1
M 57 DE93-30577A ASSY CONTROL-BOX;230V50Hz,CK95,WHT 1
M 58 DE74-20105B TRAY-CRUSTY;T5,P1300,H30,830G,TEFLON-COAT 1 CK96T/CK98F
M 59 DE74-20015B TRAY-COOKING;GLASS,T6.0,PI318,1050G,MW5630T 1
M 60 DE92-90189D ASSY-GUIDE ROLLER;D19,STD 1
M 61 DE67-60026C COUPLER;PTFE,12G.WHT,MB245 1
M 62 DE74-40001A SPIT-BARBECUE;MSWR,CE945G,SNC2 1 CK97B/CK98F
M 63 DE67-60074A COUPLER-BARBECUE;PTFE,29G,WHT,CE104CF 1 CK97B/CK98F
M 64 DE72-80062A SHAFT-BARBECUE;STS304,D3,L149,W60.25,CE97 3 CK97B/CK98F
M 65 DE92-90019P ASSY-WIRE RACK;CE1279KSE,HIGH 1
M 66 DE92-90019R ASSY-WIRE RACK;CE1279KSE,LOW 1
M 67 3601-000448 FUSE-FERRULE;250V,10A,SLOW-BLOW,CERAMIC 1 NOISE-FILTER
M 68 3601-001126 FUSE-FERRULE;250V,1.6A,QUICK-ACTING,CERAMIC 1 NOISE-FILTER
