7-2 Main Parts List
7-2 Samsung Electronics
Exploded Views and Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks
M 1 DE70-30001A PANEL-OUTER;SECC,T0.6,360,1128,EPOXY-COATI 1
M 2 DE63-90035H CUSHION-RUBBER;DFA20,T2,W190,L200,BLK 1
M 3 DE61-50565A BRACKET-UPPER;SECC,T0.5,W362,L294,-,CK95 1
M 4 DE61-50564A BRACKET-TCO;SECC1,T0.6,W45,L21,-,CK95 1
M 5 DE61-70060A SPRING-PLATE;SK-5,T0.5 1
M 6 DE61-30006A SUPPORTER-HEATER;ALUMINA,5G,2ND-W/P 1
M 7 DE47-70031G HEATER-GRILL;D6.6,230V1280W,M9G45,SJH 1
M 8 DE63-20017A GASKET-HEATER;BRASS,T1.5,OD30.5,ID22.5 1
M 9 DE60-40009B WASHER-TEFLON;SLOT,ID22.2,OD28,T1.2,TEFLON 1
M 10 DE61-50021A BRACKET-FLANGE;SECC1,T0.8,32,32 1
M 11 DE61-50347A BRACKET-EARTH;M16,T1.0,SECC,ZNC3 1
M 12 DE61-50027B BRACKET-HEATER;SECC,T1.0,W51,L55,CE945GF 1
M 13 DE61-50570A BRACKET-AIR GUIDE;ALCOAT,T0.6,W233.5,L55,-,CK95 1
M 14 DE65-20014A CABLE CLAMP;DA-6N,NY-66 1 P-CORD
M 15 DE39-20058C ASSY POWER CORD;KKP-4819D/B232,250V16A,L1700,G 1
M 16 DE71-60448A COVER-BACK;SCP3(Cr),T0.6,-,-,-,CK95 1
M 17 DE92-90478C ASSY-CASING;CK95 1
M 18 DE91-40093A ASSY NOISE FILTER;SN-E10D,250V,10A 1
M 19 DE31-10156A MOTOR-FAN;SMF-945EA,230/50,2400,M97G45 1
M 20 DE39-40758A WIRE HARNESS-A;230V50HZ,CK95 1
M 21 DE62-90102A ADIABATIC-RIGHT;SUPER FINE INSULATIO,T3,W213.3 1
M 22 DE71-60447A COVER-ADIABATIC;SECC,T0.6,W220.3,L305.1,-,CK95 1
M 23 DE74-20022A TRAY-OIL;GLASS(NEOREX) T5,P1210,600G 1 CK97B/CK98F
M 24 DE47-20009A THERMOSTAT;PW2N-520PB,160/60,250V/7.5A,H, 1
M 25 DE61-50490A BRACKET-TCO;SECC1,T0.6,34,58 1
M 26 4713-001031 LAMP-INCANDESCENT;230V,173mA,40W,ORG,-,-,25x69mm 1
M 27 DE03-30035A MAGNETRON;OM75PH((31)ESS 1
M 28 DE71-60016C COVER-AIR;NYLON#66,-,-,-,BLK,CK95 1
M 29 DE63-90090A CUSHION-DOOR;PE-FOAM,T0.5,W420,L420 1 DOOR
M 30 DE93-20020D ASSY BODY LATCH;M959/XSA 1
M 31 DE66-40021B LATCH-BODY;NYLON#66(2021SW),40g,M959/XSA 1
M 33 3405-000178 SWITCH-MICRO;250V,15A,200gf,SPST-NO 2
M 34 3405-000175 SWITCH-MICRO;250V,15A,200gf,SPST-NO 1
M 35 DE66-90054B LEVER-SWITCH;NYLON#66(2021SW),40G,M959/XSA 1
M 36 DE26-10100A TRANS-H.V;SHV-945EG1,230V,2280V/3.15V,50 1
M 37 2501-001019 C-OIL;1.10uF,2100V,BK,35X54X90,20mm 1
M 38 DE61-50106A BRACKET-HVC;SECC,T0.8,W31,L125.8 1
M 39 DE59-40001A DIODE-H.V;HVR-1X-32B-12 1
M 40 DE91-70061A ASSY-H.V.FUSE;THV060T-0800-H,5KV/0.8A,WHT 1
: Option Parts
: Warning
:Electrostatically Sensitive Devices
