Disassembly and Reassembly
3-11
Samsung Electronics
3.4.6 SMPS board
3.4.7 LSU Unit
1. Remove the all harness and 4 screws. And
remove the SMPS board.
1. To remove the LSU from the bottom of the SET,
2 screws. And remove the 3 screws.
2.
Release the LSU unit after remove the 2 Flat
cable.
rst remove the harness cover after remove the
To Next Page
