Disassembly and Reassembly
3-12
Samsung Electronics
3.4.9 Transfer roller
1. Remove the Transfer roller assy from the rear
cover by pressing the hook.
1. Remove the sub PBA. And release the Guide
Pick up unit after remove the 4 screws.
2. Release the holder pad after remove the hook of
both side.
To Next Page
