Samsung DA-E570 - APPENDIX; Product Specifications

20
SPECIFICATIONS
Model name
DA-E570
GENERAL
Power supply DC 12V 2A
Power consumption 11.2W
Weight 4.4 Ibs
Dimensions (W x D x H) 11.8 x 6.69 x 3.7 inches
Operating temperature range +41°F to +95°F
Operating humidity range 10 % to 75 %
AMPLIFIER
Rated output power
5W/CH, 4O
HM, THD = 10%, 1kHz
Input sensitivity/
Impedance
800mV/20K
ohm
S/N ratio (analog
input)
65 dB
Separation(1kHz) 60 dB
FREQUENCY
RESPONSE
Analog input
20Hz~22kHz(±3 dB)
DOCKING
RATING
iPod
5 V 1.0 A
Galaxy 5 V 1.0 A
* S/N ratio, distortion, separation, and usable sensitivity are based on measurement using AES (Audio Engineering
Society) guidelines.
* Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
appendix
