Samsung DA-E650 - Appendix; Product Specifications

26
SPECIFICATIONS
Model name
DA-E650/ DA-E651
GENERAL
Weight 3.2 kg
Dimensions (W x D x H) 630.8 x 192.3 x 162.9 mm
Operating temperature range +5°C~+35°C
Operating humidity range 10 % to 75 %
AMPLIFIER
Rated output power
40W, 4O HM, THD = 10%, 1kHz
Input sensitivity/
Impedance
800mV/56Kohm
S/N ratio (analog
input)
65 dB
Separation(1kHz) 65 dB
FREQUENCY
RESPONSE
Analog input 20Hz~20kHz(±3 dB)
Digital input/48kHz PCM 20Hz~20kHz(±3 dB)
DOCKING
RATING
iPad
5 V 2.0 A
iPod
5 V 1.0 A
Galaxy
5 V 1.0 A
USB
Type A
USB 1.1
DC output
500mA
* S/N ratio, distortion, separation, and usable sensitivity are based on measurement using AES (Audio Engineering
Society) guidelines.
* Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- For the power supply and Power Consumption, refer to the label attached to the product.
appendix
