Samsung DA-E651 - Appendix; 26 Specifications

26
appendix
SPECIFICATIONS
Model name
DA-E650/ DA-E651
GENERAL
Power supply DC 14V 4A
Power consumption 29.8W
Weight 7.1 Ibs
Dimensions (W x D x H) 24.8 x 7.6 x 6.4 inches
Operating temperature range +41°F to +95°F
Operating humidity range 10 % to 75 %
AMPLIFIER
Rated output power
40W, 4O
HM, THD = 10%, 1kHz
Input sensitivity/
Impedance
800mV/56Kohm
S/N ratio (analog
input)
65 dB
Separation(1kHz) 65 dB
FREQUENCY
RESPONSE
Analog input
20Hz~20kHz(±3 dB)
Digital input/48kHz PCM 20Hz~20kHz(±3 dB)
DOCKING
RATING
iPad
5 V 2.0 A
iPod
5 V 1.0 A
Galaxy
5 V 1.0 A
USB
Type A
USB 1.1
DC output
500mA
* S/N ratio, distortion, separation, and usable sensitivity are based on measurement using AES (Audio Engineering
Society) guidelines.
* Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
