English - 23
02 INSTALLATION
5. Remove the two screws from the opposite side of the door hinge.
6. While holding down the upper hook (A) using the flat-head
screwdriver in your right hand, pull out the upper area of the holder
lever with your left hand to remove.
7. Reassemble the two screws on the inside holes.
8. Remove a screw from the door hinge.
The screw is for pre-fixing the door to the frame front.
9. Reassemble the screw in the other hole.
10. Place the door on the other side and reattach it to the dryer.
DV5000H_DC68-03381A-19_EN.indd 23 2020-03-09 1:45:50
