Samsung DV80F5E5HGW User Manual

English - 18
operating Instructions, tips
To reduce the risk of fi re, electric shock, or injury to persons, read the IMPORTANT SAFETY
INSTRUCTIONS before operating this appliance.
If the Anti Crease option is not selected, take out the laundry immediately after it is washed and dried.
Leaving the laundry inside the drum may produce wrinkles.
OVERVIEW OF THE CONTROL PANEL
1
Digital Graphic
Display
Displays the remaining drying cycle time, all cycle information, and error
messages.
The display window shows the estimated time remaining in the cycle after you
have pressed the Start/Pause button. The estimated time remaining may
fl uctuates as the cycle progresses.
The Drying light will illuminate and remain lit until the cycle is complete.
When your dryer is in the cool-down phase, the Cooling light will illuminate.
When your dryer is in the Anti Crease phase, the “Anti Crease light” will
illuminate.
When the cycle is complete, “End” will appear in the display panel until you
push the Start/Pause button or the Power button. If your dryer is paused
during a cycle, the indicators will light up until you press the Start/Pause
button.
WARNING
3 4 5 6 71
108 9 11
2
3 4 5 91
10 11
2
[DV9, DV8 Series]
[DV7 Series]
DV90F5E6HGW-03297A-07_EN.indd Sec5:18DV90F5E6HGW-03297A-07_EN.indd Sec5:18 2014-11-12  7:54:482014-11-12  7:54:48

Samsung DV80F5E5HGW Specifications

General

Control type	Buttons, Rotary
Display type	LED
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	Yes
Appliance placement	Freestanding
Cycle time	170 min
Noise level	65 dB
Drying class	B
Drum capacity	8 kg
Current	4 A
AC input voltage	230 V
AC input frequency	50 Hz
Energy consumption	- kWh
Annual energy consumption	235 kWh
Package depth	695 mm
Package width	666 mm
Package height	885 mm
Package weight	54000 g

Weight and Dimensions

Width	600 mm
Height	850 mm
Weight	50000 g
