Installation
English36
6. Remove the two screws above and below the lever
holder on the opposite side of the door opening.
7. Remove the two screws that hold the lever holder in
place, and then remove the lever holder.
8. Re-insert the two screws that held the lever holder
into the same screw holes, and then tighten.
9. Remove the single screw from the back of the door
hinge.
NOTE
This is the screw that supports the door against the
frame so you can unscrew or screw in the hinge without
needing to support the door yourself.
