Basic System Commissioning
47
Setting Hydro Unit Options
▪ On/Off operation input
▪ Module Controller / DMS or External contact
▪ Water temperature setting input
▪ Module Controller / DMS or External contact
▪ Operation mode (Cool/Heat, Normal/Hot water) input
▪ Module Controller / DMS or External contact
▪ Demand control input
▪ Module Controller / DMS or External contact
▪ Power Demand Level – Default 100%
▪ Selectable from 50% to 95%
▪ Quiet function input
▪ Module Controller / DMS or External contact
▪ Quiet function level
▪ 100% Default
▪ Level 1 – Level 2 – Level 3
▪ Forced fan function input
▪ Module Controller / DMS or External contact
▪ “Water Law” input
▪ Module Controller / DMS or External contact
▪ “Water Law” control standard
▪ Outdoor ambient/Room temperature
▪ “Water Law” Air Cool 1 – Air Cool 2
▪ “Water Law” Room Cool 1 – Room Cool 2
▪ “Water Law” set temp Tcool 1- Tcool 2
▪ “Water Law” OD temp for Heat AirHeat1 – AirHeat2
▪ “Water Law” Room Heat1 – Room Heat2
▪ “Water Law” set temp Theat1 – Theat2
▪ Remote error reset input
▪ Enable/Disable
▪ Setting unit address – 0 to 15 each unit
▪ Confirm delay for unsecured water flow rate
▪ 10 to 240 sec. (factory default 30 sec.)
▪ External water outlet temperature sensor
▪ Enable/Disable (Default)
▪ Operation On/Off by external contact
▪ Low water temperature function (requires antifreeze)
▪ Disable(Default)/Enable
