Samsung HARD DISK DRIVE - Connector and Jumper Pin Assignment; 40 Pin I;O Connector Interface Signals; Jumper Pin Assignment

VANGO(VL40)

SAMSUNG HARD DISK DRIVE
Number Signal Number Signal Remarks
1 RESET- 2 GND
3 DD7 4 DD8
5 DD6 6 DB9
7 DD5 8 DB10
9 DD4 10 DB11
11 DD3 12 DB12
13 DD2 14 DB13
15 DD1 16 DB14
17 DD0 18 DB15
19 GND 20 Key Pin
21 DMARQ 22 GND
23 DIOW - : STOP 24 GND
25 DIOR - : HDMARDY
: HSTROBE
26 GND
27 IORDY : DDMARDY
:HSTROBE
28 CSEL
29 DMACK 30 GND
31 INTRQ 32 IOCS16
33 DA1 34 PDIAG - : CBLID -
35 DA0 36 DA2
37 CS0- 38 CS1-
39 DASP- 40 GND
3. Connector / Jumper Pin Assignment
                   
                   
oooo
+GG+
12NN5
VDDV
HDA BASE
   
   
JUMPER PIN

Jumper Pin Assignment

40 Pin I/O Connector Interface Signals
PCBA components side
