English
SIRCH
y Introduction
SIRCH (Samsung Interactive Remote Control for Hospitality) is a professional interactive remote controller for DTV that
lets you deliver TV firmware updates, cloning data, and channel mapping changes to several hundred hospitality TVs
simultaneously. Mounted at the broadcast head-end system in hotels, motels, resorts, hospitals, and apartment buildings, it
delivers modulated RF control signals to hospitality sets in each guest room through coax cable.
SIRCH includes PC embedded systems and cable RF modulators which have DVB-C (Europe) and OpenCable (North
America) RF output. It also has a 40GB Solid State hard drive, and a 100/1000 Base-T Ethernet port which lets you load TV
firmware updates.
✎
SIRCH is sold separately.
y System Block Diagram (eg. Headend System in Hotel)
SIRCH
Headend System for Hotel
HD ENCODULATOR
HD ENCODULATOR
HD ENCODULATOR
HD ENCODULATOR
Satellite Receiver
Independence AV Stream
Cable STB
Terrestrial Receiver
RF Combiner
y Features
– SIRCH Windows Application SW
– 19 inch Rack Unit type, PC embedded Modulator : OpenCable.
– Remote Upgrade (TV Software, Cloning Data, Channel Map)
– Operation can be controlled by key button, extra key board, monitor, and mouse.
– Low Phase noise, High MER, 50~870MHz, +7 ~ -30dBm RF output.
y Cautions
– SIRCH can operate only in TV RF mode. (OpenCable QAM Modulation).
– You can install SIRCH only on TVs in the stand-alone mode. (Power On Source should be TV).
– SIRCH operates only when the SIRCH application version is higher than the TV’s SIRCH version.
– You must check the SIRCH application version to ensure it is compatible with the TV firmware version.
– The SIRCH function is not supported for satellite channels.
(To use the SIRCH function in satellite models, make sure to set the Power On Channel to an Air or Cable channel.)
