28
Connections
CONNECTING AUDIO FROM EXTERNAL COMPONENTS
OPTICAL : Connecting an External Digital Component
Digital signal components such as a Cable Box/Satellite receiver (Set-Top Box).
Connect the Digital Input (OPTICAL) on the main unit to the Digital Output of the external digital
component.
Press the FUNCTION button on the main unit to select D.IN input.
The mode switches as follows : BD/DVD ➞ D.IN ➞ AUX ➞ BT AUDIO ➞ FM.
To see video from your Cable Box/Satellite receiver, you must connect it's video output
to a TV.
This system supports Digital sampling frequencies of 32 kHz of higher from external digital This system supports Digital sampling frequencies of 32 kHz of higher from external digital
components.components.
This system supports only DTS and Dolby digital audio, MPEG audio which is bitstream
cannot be supported.
1.
2.
•
M
Optical Cable
(not supplied)
HT-BD7255_ELS_0511-1.indd 28HT-BD7255_ELS_0511-1.indd 28 2009-05-19 5:31:532009-05-19 5:31:53
