3-2 Samsung Electronics
Disassembly & Reassembly
No. Description Description Photo
2 2) Loosen hooks from CABINET-BOTTOM.
3) Disconnect wire, then remove the
CABINET-BOTTOM.
3 1) Unfasten 1 screw, then remove ASSY PCB FRONT.
