Samsung Electronics 3-1
Disassembly & Reassembly
3. Disassembly & Reassembly
3-1 Overall Disassembly & Reassembly
- Be careful to follow the disassembly sequence described in the manual. Otherwise, the product
may be damaged.
- Be sure to carefully read and understand the safety instructions before performing any work as
the IC chips on the PCB are vulnerable to static electricity.
- In order to assemble reverse the order of disassembly.
No. Description Description Photo
1 1) Unfasten 5 screws on the DECO-SIDE.
2) Remove DECO-SIDE & TOP on the direction of Rear.
2 1) Unfasten 1 screw to remove CABINET-FRONT.
To Next Page
