3-4 Samsung Electronics
Disassembly & Reassembly
No. Description Description Photo
6 1) Unfasten 2 screws and 1 wire, then remove
ASSY PCB MAIN.
7 1) Unfasten 5 screws to remove AMP and FAN.
