Samsung Electronics 5-4
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Part List
Loc. No. Code No. Description;Specification Qty. SNA Remark
BSF01 AK61-00985A BRACKET-SHAFT FIX R;BD-P6,SUS 301 CSP,T0.35 2 SA
FFD01 AK41-00931A FFC-DECK;BD-C5500,A TYPE,PITCH 1.0,22P,T0.11,L 1 SA
FL346 AK41-00930A FFC-PU;BD-C5500,B TYPE,PITCH0.5,40P,T0.11,L250* 1 SA
H100 AK96-01219A ASSY BRACKET P-TRAVERSE DECK;BD-P6,BRKT 1 SA
H110 AK96-01220A ASSY FRAME P-MAIN;BD-P6,FRAME+GEAR+PCB 1 SA
H300 AK96-01216A ASSY HINGE P-PU;BD-P6,POM+SPRING 1 SA
H400
AK96-01217A ASSY COVER P-UPPER;BD-P6,COVER UPPER + 1 SA Black
AK96-01217B ASSY COVER P-UPPER;BD-P6,COVER UPPER + 1 SA
Transparency
H500 AK63-00606A COVER-BOTTOM;BD-P6,EGI-SECC,TO.5 1 SA
PICKUP
AK96-01213A ASSY PICK UP P;SOH-BP6 1 SA
AK96-01236A ASSY PICK UP P;SOH-BP6 1 SA
AK96-01239A ASSY PICK UP P;SOH-BP6 1 SA
AK96-01244A ASSY PICK UP P;SOH-BP6 1 SA
W012 6002-001086 SCREW-TAPPING;PH,+,B,M1.7,L5.0,ZPC(WHT) 6 SA
W350 6001-001003 SCREW-MACHINE;BH,+,M2.6,L6,ZPC(BLK) 4 SA
W381 6003-001449 SCREW-TAPTYPE;BH,+,B,M2.6,L6,NI PLT,SWRCH18A 2 SA
