Samsung HT-C5200/EDC User Manual

Samsung Electronics 6-5
PCB Diagram
6-3-1 Pin Connection
1 VCON2
Volume Interface Connector
Pin No. Signal
1 VOL DOWN
2 VOL UP
3 VOL LED
4 GND
5 5V
2 TOCN1
Volume Interface Connector
Pin No. Signal
1 VOL DOWN
2 VOL UP
3 VOL LED
4 GND
5 5V
6 KEY SDA
7 KEY SCL
8 LED1
9 GND
10 5V
11 5V
12 GND
13 KEY
14 GND
15 PWR ON
3 PCON2
Power Key Interface Connector
Pin No. Signal
1 PWR ON
2 GND
3 KEY
4 GND
5 5V
4 PCN1
Power Key Interface Connector
Pin No. Signal
1 5V
2 GND
3 KEY
4 GND
5 PWR ON
