Samsung Electronics 6-15
PCB Diagram
6-8-1 Pin Connection
2 CON2
AMP Power Connector
Pin No. Signal
1 SGND
2 ST5.4V
3 ST5.4V
4 ST5.4V
5
SGND
6 SGND
7 D12V
8 D12V
9 SGND
10 SGND
11 P_ON
12 VFD+
13
VFD-
14 VFD -32V
15 SGND
16
SGND
1 CON3
MAIN Power Connector
Pin No. Signal
1 VARIABLE PWR C
2 PVDD -30V
3 PVDD -30V
4 PVDD -30V
5
SGND
6 SGND
7 SGND
8 PVDD +30V
9 PVDD +30V
10
PVDD +30V
