18
CONNECTIONS
Subwoofer: The subwoofer is active, with a built-in a 150W
amplifier, and outputs rich bass through 8 inch
speaker units. You can listen to the optimal LFE
(bass) by using the subwoofer-only volume control
and the variable crossover control.
•
The control is calibrated from –6dB (minimum) to
+6dB (maximum).
Crossover: The Crossover sets the cutoff frequency for the
subwoofer. Set the Crossover control for the best
bass response in your room.
•
You can adjust the bass or treble output from the
front, rear, center speakers and the subwoofer.
•
To the left increases the bass and to the right,
treble.
Connecting Main Unit to Subwoofer
Subwoofer Function
Use the supplied DIN audio connection cable to
connect DIN Audio Out on the main unit to DIN Audio
Input on the subwoofer.
Press the subwoofer power button on the subwoofer
to turn on the power.
1
2
The DIN Audio Connection Cable on this product contains lead, a chemical known to the State of
California to cause [cancer,and]birth defects or other reproductive harm.
Wash hands after
handling.
Waring
1p~44p(DS1000)-sea 9/15/04 2:43 PM Page 21
