29
ENG
● APPENDIX
SPECIFICATIONS
Model name
HW-E550/E551
GENERAL
Weight
Main unit 1.7 kg
Subwoofer 7.2 kg
Dimensions
(W x H x D)
Main unit 1088 x 55 x 55 mm
Subwoofer 290 x 290 x 380 mm
Operating temperature range + 5 °C to 35 °C
Operating humidity range 10 % to 75 %
AMPLIFIER
Rated output
power
Main unit 80W/CH, 3ohm,
THD = 10%, 1kHz
Subwoofer 150W, 3ohm, THD=10%, 100Hz
Input sensitivity/
Impedance 570mV/20K
ohm
S/N ratio (analog
input)
70dB
Separation(1kHz) 65dB
FREQUENCY
RESPONSE
Analog input 20Hz~20kHz(±3dB)
Digital input/48kHz PCM 20Hz~20kHz(±3dB)
* S/N ratio, distortion, separation and usable sensitivity are based on measurement using AES (Audio
Engineering Society) guidelines.
*: Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- For the power supply , refer to the label attached to the product.
