6 Electrical Parts List
6-1
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LE40M87BDX/BWT LE40M87BD,N30A/40M80-GTU,40,LCD-TV,RUSSI
0.1 M0001 BN90-01158B ASSY COVER FRONT;40M87,EO(IDTV),-,ABS+PM 1 S.N.A
..2 T0003 BN96-04643B ASSY COVER P-FRONT;40M87,EO(IDTV),-,ABS+ 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 1.983 S.N.A
...3 M0112 BN63-03001B COVER-FRONT;40M81,EO(IDTV),ABS+PMMA,-,-, 1 S.N.A
...3 BN63-03035B COVER-DECORATION L;40M81,ABS,HB,IV-16,LE 1 S.N.A
...3 BN63-03036B COVER-DECORATION R;40M81,ABS,HB,IV-16,RI 1 S.N.A
...3 T0022 BN64-00550A KNOB-CONTROL;40M81,ABS,-,-,-,HB,IV-16,-, 1 S.N.A
...3 T0066 BN96-04642C ASSY COVER P-DECORATION;40M81,SO,-,ABS,H 1 S.N.A
....4 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
....4 T0056 BN63-03005B COVER-DECORATION;40M81,ABS,-,-,-,HB,-,IV 1 S.N.A
....4 T0056 BN63-03037A COVER-DECORATION;40M81,ABS+PMMA,-,-,-,HB 1 S.N.A
....4 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
....4 T0023 BN64-00548A KNOB POWER;TULIP40,PC VIOLET,V0 1 S.N.A
....4 T0054 BN64-00549A KNOB-DECORATION;40M81,ABS,-,-,-,HB,IV-16 1 S.N.A
....4 BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 0.8 S.N.A
...3 M0146 BN96-04884C ASSY BOARD P-POWER & IR;LNT4042HX/XAA,CT 1 S.A
...3 M0145 BN96-04901A ASSY BOARD P-FUNCTION;LNT3771FD,CT5000-4 1 S.A
...3 BN63-01151A FELT-NON WOVEN;MM17NS,T0.5,393,10,BLACK 4 S.N.A
...3 T0069 AA60-00171E SPACER-FELT;43L2,FELT,300,T0.5,5 2 S.N.A
..2 T0175 BN96-04771A ASSY SPEAKER P;8ohm,4pin,Enclosure Type, 1 S.A
0.1 M0002 BN90-01163B ASSY COVER REAR;40M81,EO(IDTV),-,ABS+PMM 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 M0013 BN96-04746A ASSY COVER P-REAR;40M81,EO(IDTV),ABS+PMM 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 0.99 S.N.A
...3 M0006 BN63-03038A COVER-REAR;40M81,EO(IDTV),ABS+PMMA,-,-,- 1 S.N.A
...3 T0071 BN64-00555B INLAY-TERMINAL;07,COMMON,EO(IDTV),PS SHE 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0101 BN61-03348A BRACKET-WALL;LCD TV 32",SECC T1.6 2 S.N.A
0.1 M0216 BN90-01168A ASSY STAND;37,40M81,-,ABS+PMMA,HB,BK23,H 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0027 BN96-04640A ASSY STAND P-BASE;37,40M81,-,ABS+PMMA,HB 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 8 S.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 T0920 BN61-02877A GUIDE-STAND;TULIP,40,ABS,V0,-,-,-,-,- 1 S.N.A
....4 BN61-02981A BRACKET-SUPPORT STAND;40 BORDEAUX PLUS,S 1 S.N.A
....4 BN61-03045A BRACKET-SUPPORT STAND;40 BORDEAUX PLUS,S 1 S.N.A
...3 BN61-02883A BRACKET-STAND BOTTOM;BORDEAUX PLUS,40,SE 1 S.N.A
...3 BN61-02885A HOLDER-SWIVEL RING;MURANO40,ACETAL NATUR 1 S.N.A
...3 BN61-02886A BRACKET-HINGE SWIVEL;BORDEAUX PLUS,40,SE 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 T0004 BN63-03030A COVER-STAND BASE;40R81,ABS+PMMA,-,-,-,HB 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,CR Rubber Gray,T1.5 4 S.N.A
0.1 BN91-01342K ASSY LCD-AUO;LE40M87BDX/* 1 S.N.A
..2 M0215 BN07-00465A LCD-PANEL;T400HW01 V1,8bit,40inch,16.7M, 1 S.A
0.1 M0017 BN91-01407L ASSY CHASSIS;LE40M87BDX/*72% 1 S.N.A
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE40M87BDX Parts List
