English - 5
1 EX-LINK
Connector for service only.
2 DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component such as a Home theater receiver.
3 PC IN [PC] / [AUDIO]
Connects to the video and audio output jacks on your PC.
4 H (HEADPHONE)
Connects a set of external headphones for private listening.
5 HDMI (DVI) IN / DVI AUDIO IN [R-AUDIO-L] (LN22B460)
Connects to the HDMI jack of a device with an HDMI output.
No sound connection is needed for an HDMI to HDMI connection.
Use the HDMI (DVI) IN jack for DVI connection to an external device. Use a DVI to HDMI cable or DVI-HDMI adapter
(DVI to HDMI) for video connection and the DVI AUDIO IN [R-AUDIO-L] jacks for audio.
When using an HDMI/DVI cable connection, you must use the HDMI (DVI) IN jack.
You can also use the ports to connect to a PC.
6 HDMI IN 1(DVI), 2, 3 / DVI AUDIO IN [R-AUDIO-L] (LN26B460, LN32B460)
Connects to the HDMI jack of a device with an HDMI output.
No sound connection is needed for an HDMI to HDMI connection.
Use the HDMI IN 1(DVI) jack for DVI connection to an external device. Use a DVI to HDMI cable or DVI-HDMI
adapter (DVI to HDMI) for video connection and the DVI AUDIO IN [R-AUDIO-L] jacks for audio.
When using an HDMI/DVI cable connection, you must use the HDMI IN 1(DVI) jack.
You can also use the ports to connect to a PC.
7 SERVICE
Connector for software upgrades.
8 ANT IN
Connects to an antenna or cable TV system.
9 POWER INPUT
Connects the supplied power cord.
0 KENSINGTON LOCK
The Kensington Lock (optional) is a device used to physically x the system when used in a public place. If you want to
use a locking device, contact the dealer where you purchased the TV.
The location of the Kensington Lock may be different depending on its model.
! AV IN (LN22B460) / AV IN 2 (LN26B460, LN32B460)
Video and audio inputs for external devices, such as a camcorder or VCR.
@ COMPONENT IN (LN22B460)
Connects Component video / audio.
# COMPONENT IN 1, 2 / AV IN 1 (LN26B460, LN32B460)
Connects Component video / audio. The COMPONENT IN 1 jack is also used as the AV IN 1 jack.
Connect the video cable to the COMPONENT IN 1 [Y/VIDEO] jack and the audio cable to the COMPONENT IN 1
[R-AUDIO-L] jacks.
$ AUDIO OUT
Connects to the audio input jacks on your Amplier/Home theater.
–
–
–
–
–
