Samsung M945CE - Door Parts List; Control Parts List

Samsung Electronics 7-3
Ref. No Parts No. Description / Specification Q'ty Remarks
D 1 DE67-20003W SCREEN-DOOR(B);ACRYL ,T1.5,W107.4,L401.5,WHT,M945CE/XSA,- 1
D 2 DE02-00125A TAPE-DOUBLE FACE;ACRYL,T0.45,W9,WHT,WF103,#4420 0.58 DOOR/A
D 3 DE64-40011A DOOR-A;RESIN-ABS(HR-0370U),T2.5,M945( 1
D 4 DE92-50127H ASSY DOOR-E;COATING,BLACK,T0.8,-,-,-,- 1
D 5 DE64-40012A DOOR-C;RESIN-PP(TB53),T2.0,CE945GF,BL 1
D 6 DE64-40006D DOOR-KEY;NYLON#66,(2021SW),BLK,M945(EUW 1
D 7 DE61-70032A SPRING-KEY;ES,HSWR,PI0.6,D5.4,L25,MW8640T 1
D 8 DE61-80002A HINGE-UPPER;SCP1,T2.3,26,77,ZPC3,WHT,CE945 1
D 9 DE61-80003A HINGE-LOWER;SCP1,T2.3,26,77,ZPC3,WHT,CE945 1
D10 DE01-00002B FILM-DOOR;PC,T0.15,275,175,MW5574W 1
Ref. No. Parts No. Description/Specification Q'ty Remarks
C 1 DE66-20006E BUTTON-PUSH;ABS(VH-0855),P/WHT,M745(EUW) 1
C 2 DE61-70076A SPRING-BUTTON;HSWR,PI0.6 1
C 3 DE34-00003B SWITCH-MEMBRANE;PET,M945CE/XSA,-,-,-,-,-,SEAU 1
C 4 DE67-40002A WINDOW-DISPLAY;RESIN-ACRYLIC,T2.3,M945(IDEO), 1
C 5 DE72-70007B CONTROL-PANEL;RESIN-ABS,120GR,WHT(VH-0800),M 1
C 6 DE91-10401A ASSY PCB-MAIN;230V50HZ,NS,VFD,M945(EURO)NEW, 1
C 7 DE93-30539F ASSY CONTROL-PANEL;M945(EUW) 1
Ref. No Parts No. Description / Specification Q'ty Remarks
B 1 DE66-40001A LATCH-BODY;POM(F20-02),40GR,NTR 1
B 2 3405-000178 SWITCH-MICRO;250V,15A,200gf,SPST-NO 2
B 3 3405-000175 SWITCH-MICRO;250V,15A,200gf,SPST-NO 1
B 4 DE66-90001A LEVER-SWITCH;P.O.M(F20-02),2,6,NTR,2ND-W-P/ 1
Exploded Views and Parts List
7-5 Body Latch Parts List
7-4 Control Parts List
7-3 Door Parts List
