NR201 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
NR202 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
NR105 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR995 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR996 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR997 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR998 2007-000830 R-CHIP;39KOHM,5%,1/10W,DA,TP,2012
NR53L 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR53R 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR55L 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR55R 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
SR2 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
NR117 2007-000898 R-CHIP;430Kohm,5%,1/10W,DA,TP,2012
NR108 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
NR111 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
NR112 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
NR116 2007-001195 R-CHIP;820KOHM,5%,1/10W,DA,TP,2012
NR994 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
NR999 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
2007-001216 R-CHIP;82OHM,5%,1/10W,DA,TP,2012
NC107 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC108 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC119 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC120 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC121 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC600 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC901 2203-000199 C-CERAMIC,CHIP;100nF,79.8,50V,Z5U,TP,2012,-
NC1 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC103 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC112 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC113 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC116 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC205 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC502 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC503 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC504 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC53L 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC53R 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC602 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC800 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC804 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC905 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
SC1 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
SC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
SC6 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC190 2203-000335 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,2012,2.0m
NC117 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,2012,-
NC110 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,2012,-,TP
NC118 2203-000787 C-CERAMIC,CHIP;330pF,5%,50V,NPO,TP,2012,-
NC101 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC111 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC125 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC100 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012,-
NC106 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012,-
NC124 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,2012,
NC204 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,2012,
NC200 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
NC115 2203-001137 C-CERAMIC,CHIP;68nF,+80-20%,50V,Y5V,TP,2012,-
NC104 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC52L 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC52R 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC603 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC903 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC102 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
NC201 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
NC202 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,TP,2012,2MM
NC203 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,TP,2012,2MM
NL105 3301-000325 CORE-FERRITE BEAD;AB,3.2x2.5x1.3mm,-,-
SIC1 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
SIC2 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
NXF100 2802-000211 RESONATOR-CERAMIC;16.93MHZ,0.5%,TP,10.0X5.0X10.0
SCW5 3708-001131 CONNECTOR-FPC/FC/PIC;5P,1.25mm,STRAIGHT,SN
NCW100 3708-001312 CONNECTOR-FPC/FC/PIC;16P,1mm,STRAIGHT,SN
3711-000906 CONNECTOR-HEADER;BOX,3P,1R,2mm,ANGLE,SN
SCW1 3711-002579 CONNECTOR-HEADER;WALL,22P,1R,2.5MM,ANGLE,
SCW7 3711-003379 CONNECTOR-HEADER;NOWALL,3P,1R,2.5MM,STRAIGHT,SN
NCW101 AH39-20025S LEAD-CONNECTOR,ASSY;-,51004-08,35023-08,8P,300MM,1
NCW102 AH39-20561P LEAD CONNECTOR-ASSY;-,5295,PHR,6P,150mm,1007#28
ND200 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND201 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND202 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND203 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
SZD1 0403-000352 DIODE-ZENER;UZ4.7BM,4.7V,4.4-5.0V,500MW,DO
SZD2 0403-000361 DIODE-ZENER;UZ6.2BSB,6.2V,5.99-6.24V,50
NQ1501 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
SR1 2001-000027 R-CARBON;100ohm,5%,1/4W,AA,TP,2.4x6.4mm
NR106 2001-000319 R-CARBON;120Kohm,5%,1/8W,AA,TP,1.8x3.2m
NR1 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
NR2 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
NR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
NR113 2001-000977 R-CARBON;8.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
NR555 2008-000141 R-FUSIBLE;2.2ohm,5%,1/4W,AA,TP,2.6x6.7mm
NC400 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP
NC300 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
NC117 2301-000389 C-FILM,PEF;150nF,5%,50V,TP,12.5x15x7.5,7m
NC105 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC501 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC702 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC904 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
SC14 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC114 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
NC301 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
NC700 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
NC701 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
SC5 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
NC703 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
NC122 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC50L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC50R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC54 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NL101 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL102 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL100 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
SL1 2701-000179 INDUCTOR-AXIAL;33uH,10%,4.2x9.8mm
NL300 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NL301 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NL302 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NIC05 AC14-12001G IC;KA78L05,T,-
SCO4 AC14-12001G IC;KA78L05,T,-
AJ59-20150T DECK-CDP;CMS-300,-,-,-,-
SPK PS960E/AMF SPEAKER-SYSTEM;MAX960
***** MAX980 Parts List *****
AH26-80144J TRANS-POWER;E185.8X63,110/220V,50/60Hz,MAX98
AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,VDE
DECK AH59-20006B DECK-CASSETTE;ADR2113MW,MAX950,DC12V,DOUBLE
AH90-10752Y ASSY-PCB-TUNER;MAX900,CE+RDS BAND S.N.A.
TFL4 14529-304-610 FILTER CERAMIC;AHCM2-450BL
TX1 2801-000734 CRYSTAL-UNIT;7.2MHZ,50PPM,28-AAM,12PF,30OHM
TFL2 2903-000105 FILTER-CERAMIC;BP,10.7MHZ+-25KHZ,180KHZ+-50KH
TWA1 3710-001421 CONNECTOR-SOCKET;14P,1R,2mm,ANGLE,SN
TJ2 3711-000814 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,ANGLE,SN
6003-000276 SCREW-TAPTITE;BH,+,B,M3,L10,ZPC(YEL),SWCH1018AK
HIC1 AH14-10007G IC;LC72131,DIP,STICK PLL
TIC1 AH14-10008B IC;LA1837,DIP,RF+MPX
TLPF1 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7
TLPF2 AH26-00005A TRANS-IF;-,LKS75M00-X000264-0,LOW PASS FILTER,-,7
TL2 AH26-10001E TRANS-IF;KS940228-09,-,-,7.6X12.0,-,450KHZ,BULK,
TL3 AH26-10020A TRANS-DET;-,7KLL,DET,-,7.8MM,91PF,11.32M
TC39 AH61-40022A STUD-TAP;SPC1,T0.5,BT2,-,-,
RZD1 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
RR1 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
RR4 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
RR5 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
RR2 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
RC9 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
RC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
RC7 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
RC8 2203-001058 C-CERAMIC,CHIP;560pF,5%,50V,NPO,2012,-,TP
RC4 2203-001524 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,2012,-
RC5 2203-001524 C-CERAMIC,CHIP;47pF,5%,50V,NPO,TP,2012,-
RC1 2401-000907 C-AL;22UF,20%,16V,GP,-,5X11,2MM
RC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RX1 2801-003601 CRYSTAL-UNIT;4.332MHz,30ppm,28-AAM,30pF,
RIC1 AH14-10008E IC;BU1923F,SOP,+5V
TR19 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR45 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR47 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR49 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR24 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR43 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR48 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR50 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR53 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR56 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR10 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
TR20 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR28 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
TR52 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR40 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR11 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
3-6 Samsung Electronics
