AR13 2008-000122 R-FUSIBLE;100OHM,5%,1W,AA,TP,4.3X13MM
AR15 2008-000122 R-FUSIBLE;100OHM,5%,1W,AA,TP,4.3X13MM
CVR1 2103-000004 VR-SEMI;2Kohm,30%,1/10W,SIDE
CVR2 2103-000004 VR-SEMI;2Kohm,30%,1/10W,SIDE
JSR2L 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR2R 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR3L 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR3R 2103-000122 VR-SEMI;100Kohm,30%,1/10W,TOP
JSR1L 2103-000248 VR-SEMI;200KOHM,30%,1/10W,TOP
JSR1R 2103-000248 VR-SEMI;200KOHM,30%,1/10W,TOP
RC11 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,13.5x
RC12 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,13.5x
AC3L 2201-000247 C-CERAMIC,DISC;15pF,5%,50V,CH,TP,5x3,5
AC3R 2201-000247 C-CERAMIC,DISC;15pF,5%,50V,CH,TP,5x3,5
FC1L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5
FC1R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5
JC3L 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5
JC3R 2201-000368 C-CERAMIC,DISC;220PF,10%,50V,SL,TP,6.5X3.0,5
PC1 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
PC2 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
JC4L 2201-000601 C-CERAMIC,DISC;.56NF,10%,50V,Y5P,TP,4X3MM,5
JC4R 2201-000601 C-CERAMIC,DISC;.56NF,10%,50V,Y5P,TP,4X3MM,5
JC5L 2201-000601 C-CERAMIC,DISC;.56NF,10%,50V,Y5P,TP,4X3MM,5
JC5R 2201-000601 C-CERAMIC,DISC;.56NF,10%,50V,Y5P,TP,4X3MM,5
JC2 2201-000674 C-CERAMIC,DISC;820PF,10%,50V,Y5P,BK,5.0X3.0,2
JC2L 2201-000674 C-CERAMIC,DISC;820PF,10%,50V,Y5P,BK,5.0X3.0,2
JC2R 2201-000674 C-CERAMIC,DISC;820PF,10%,50V,Y5P,BK,5.0X3.0,2
AC1L 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP,3.5x19,-
AC1R 2202-000231 C-CERAMIC,MLC-AXIAL;330pF,10%,50V,Y5P,TP,3.5x19,-
FC12 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,-
FC13L 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,-
FC13R 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,-
FC2 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,-
FC3 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,-
FC7R 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19,-
FC10L 2202-000791 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP,3.5x19,-
FC10R 2202-000791 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP,3.5x19,-
FC10 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19
FC14L 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19
FC14R 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,TP,3.5X19
AC1L 2202-000814 C-CERAMIC,MLC-AXIAL;390PF,10%,50V,Y5P,TP,3.5X19,-
AC1R 2202-000814 C-CERAMIC,MLC-AXIAL;390PF,10%,50V,Y5P,TP,3.5X19,-
FC14 2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP,3.5X19,-
FC16L 2202-000820 C-CERAMIC,MLC-AXIAL;5.6NF,20%,16V,Y5R,TP,3.5X19,-
FC13 2301-000361 C-FILM,PEF;1.2NF,10%,50V,TP,-,5MM
AC6L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
AC6R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC1 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC17 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC7L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC15L 2301-000393 C-FILM,PEF;18NF,10%,50V,TP,6.5X12.5X3.5MM
FC15R 2301-000393 C-FILM,PEF;18NF,10%,50V,TP,6.5X12.5X3.5MM
LC4 2301-000404 C-FILM,PEF;2.2NF,10%,50V,TP,5.5X7X3.2MM,5
LC1 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM
AC2 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
FC9 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC6L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC6R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
FC11 2301-000446 C-FILM,PEF;4.7NF,5%,50V,TP,6X12X3,3.5MM
JC10L 2301-000446 C-FILM,PEF;4.7NF,5%,50V,TP,6X12X3,3.5MM
JC10R 2301-000446 C-FILM,PEF;4.7NF,5%,50V,TP,6X12X3,3.5MM
FC4 2301-000449 C-FILM,PEF;47NF,10%,50V,TP,8X11X4.5MM,5MM
FC16R 2301-000454 C-FILM,PEF;5.6NF,10%,50V,TP,6X12X3,3.5MM
LC5 2301-000456 C-FILM,PEF;56NF,10%,50V,TP,8X12X4.5MM,5MM
FC15 2301-000469 C-FILM,PEF;68NF,10%,50V,TP,9X12X4.5MM,5MM
AC1 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
CC1 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
AC12 2401-000385 C-AL;10UF,20%,100V,GP,-,6.3X11,2.5M
AC9 2401-000385 C-AL;10UF,20%,100V,GP,-,6.3X11,2.5M
BC1L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC1R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC3L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
BC3R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC11L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC11R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC12L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC12R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC1L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC1R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC3 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC4 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC6 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
RC10 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
AC10 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
AC11 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
RC8 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC16 2401-000656 C-AL;2.2UF,20%,50V,GP,-,5X11,-
FC6L 2401-000656 C-AL;2.2UF,20%,50V,GP,-,5X11,-
FC6R 2401-000656 C-AL;2.2UF,20%,50V,GP,-,5X11,-
HC1L 2401-000656 C-AL;2.2UF,20%,50V,GP,-,5X11,-
HC1R 2401-000656 C-AL;2.2UF,20%,50V,GP,-,5X11,-
HC1 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
HC2 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
JC5 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
RC6 2401-001364 C-AL;470UF,20%,16V,GP,TP,10X12MM,5M
BC2 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
BC2L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
BC2R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
FC5 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
HC12L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
HC12R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
AC13 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC4L 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC4R 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
LC2 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
RC10 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
DC1L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC1R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC3L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC3R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC5L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC5R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC18 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC7L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC7R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC8L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
JC8R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
RC7 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC8 2401-001936 C-AL;22UF,20%,16V,GP,TP,5X11MM,5MM
AC2L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
AC2R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC8L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC8R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
HC3 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
RC5 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC2L 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC2R 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC3L 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC3R 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC4L 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC4R 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC5L 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
FC5R 2401-001965 C-AL;470NF,20%,50V,-,BK,4X7MM,1.5MM
AC4 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
BC1 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC7 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC1 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
LC6 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
HL1 2701-000178 INDUCTOR-AXIAL;33uH,10%,2.8x7mm
RL1 2701-000178 INDUCTOR-AXIAL;33uH,10%,2.8x7mm
AL1 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
LL2 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
RBD1 0402-001258 DIODE-BRIDGE;GBU606,600V,6A,SIP-4,BK
RQ1 0502-000303 TR-POWER;KSD882,NPN,1W,TO-126,TP,160-32
RIC1 1203-001653 IC-REGULATOR;L4959
FIC2 1204-000156 IC-EQUALIZER;BA3834S,DIP,18P,-,PLASTIC,7V,-
JIC1 1204-001471 IC-TAPE EQ;HA12211NT
BIC1 1204-001474 IC;KA22241,SIP,9P
RR1 2003-000710 R-METAL OXIDE(S);47ohm,5%,2W,AA,TP,4x12mm
AC7 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5
AC8 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5
RC13 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5
RC14 2401-000847 C-AL;220UF,20%,35V,GP,TP,10X12MM,5M
2401-000871 C-AL;220UF,20%,50V,GP,-,10X16MM,5MM
RC6 2401-001364 C-AL;470UF,20%,16V,GP,TP,10X12MM,5M
RC1 2401-001942 C-AL;3300UF,20%,35V,GP,BK,18X35.5MM
RC2 2401-001942 C-AL;3300UF,20%,35V,GP,BK,18X35.5MM
2901-001139 FILTER-EMI ON BOARD;50V,.5A,-,390PF,7X2.5X5MM,TP,RADIAL
CW1 3708-000446 CONNECTOR-FPC/FC/PIC;11P,1.5MM,STRAIGHT,
CW2 3708-000447 CONNECTOR-FPC/FC/PIC;13P,1.5MM,STRAIGHT,
PJ1 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRAIGHT,SN
AW2 3711-000820 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,STRAIGHT,SN
JCW2 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
CCW1 3711-002809 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,SN
MW1 3711-003080 CONNECTOR-HEADER;NOWALL,28P,1R,1.25MM,ANGLE,SN
JCW3 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN
JCW1 3711-003111 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,-,BRAS
RW1 3711-003112 CONNECTOR-HEADER;BOX,8P,1R,2.5MM,STRAIGHT,SN
TCW1 3711-004109 CONNECTOR-HEADER;3WALL,14P,1R,2mm,STRAIGHT,SN
SPK 3716-000209 TERMINAL-BLOCK;,-,-,60V,7A
H1 3722-000363 JACK-PHONE;9P,6.4MM,AU,BLK,-
AUX 3722-000377 JACK-RCA;4P/2C,3.5MM,SN,BLK,#16~22
JFL1L AH26-10002X COIL-TRAP;KS940830-05,BIAS-TRAP,30DB,7.6,51PF,105K
JFL1R AH26-10002X COIL-TRAP;KS940830-05,BIAS-TRAP,30DB,7.6,51PF,105K
LL1 AH26-10003C COIL-TRAP;PCHNS-5371EQJ,BIAS-TRAP,-,-,850PF,105KHZ
PL1 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
PL2 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
- AH39-20560P LEAD CONNECTOR-ASSY;-,5264,51088,8p,300m
RCW1 AH39-20560P LEAD CONNECTOR-ASSY;-,5264,51088,8p,300m
AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK
AH92-00020A ASSY-MANU-FRONT PCB;MAX960,- S.N.A.
UD14 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD15 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-9
