Samsung MAX-960 - Printed Circuit Board Diagrams; Main PCB Layout and Components

NC804 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC905 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
SC1 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
SC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
SC6 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,-
NC190 2203-000335 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,2012,2.0m
NC117 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,2012,-
NC110 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,2012,-,TP
NC118 2203-000787 C-CERAMIC,CHIP;330pF,5%,50V,NPO,TP,2012,-
NC101 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC111 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC125 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012,-
NC100 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012,-
NC106 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012,-
NC124 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,2012,
NC204 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,2012,
NC200 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012,-
NC115 2203-001137 C-CERAMIC,CHIP;68nF,+80-20%,50V,Y5V,TP,2012,-
NC104 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC52L 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC52R 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC603 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC903 2203-001537 C-CERAMIC,CHIP;1NF,10%,50V,X7R,TP,2012,-
NC102 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
NC201 2203-001551 C-CERAMIC,CHIP;1.5NF,10%,50V,X7R,TP,2012,2MM
NC202 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,TP,2012,2MM
NC203 2203-001619 C-CERAMIC,CHIP;27PF,5%,50V,NPO,TP,2012,2MM
NL105 3301-000325 CORE-FERRITE BEAD;AB,3.2x2.5x1.3mm,-,-
SIC1 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
SIC2 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
NXF100 2802-000211 RESONATOR-CERAMIC;16.93MHZ,0.5%,TP,10.0X5.0X10.0
SCW5 3708-001131 CONNECTOR-FPC/FC/PIC;5P,1.25mm,STRAIGHT,SN
NCW100 3708-001312 CONNECTOR-FPC/FC/PIC;16P,1mm,STRAIGHT,SN
3711-000906 CONNECTOR-HEADER;BOX,3P,1R,2mm,ANGLE,SN
SCW1 3711-002579 CONNECTOR-HEADER;WALL,22P,1R,2.5MM,ANGLE,
SCW7 3711-003379 CONNECTOR-HEADER;NOWALL,3P,1R,2.5MM,STRAIGHT,SN
NCW101 AH39-20025S LEAD-CONNECTOR,ASSY;-,51004-08,35023-08,8P,300MM,1
NCW102 AH39-20561P LEAD CONNECTOR-ASSY;-,5295,PHR,6P,150mm,1007#28
ND200 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND201 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND202 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND203 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
SZD1 0403-000352 DIODE-ZENER;UZ4.7BM,4.7V,4.4-5.0V,500MW,DO
SZD2 0403-000361 DIODE-ZENER;UZ6.2BSB,6.2V,5.99-6.24V,50
NQ1501 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
SR1 2001-000027 R-CARBON;100ohm,5%,1/4W,AA,TP,2.4x6.4mm
NR106 2001-000319 R-CARBON;120Kohm,5%,1/8W,AA,TP,1.8x3.2m
NR1 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
NR2 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
NR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,-
NR113 2001-000977 R-CARBON;8.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
NR555 2008-000141 R-FUSIBLE;2.2ohm,5%,1/4W,AA,TP,2.6x6.7mm
NC400 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP
NC300 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
NC117 2301-000389 C-FILM,PEF;150nF,5%,50V,TP,12.5x15x7.5,7m
NC105 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC501 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC702 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC904 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
SC14 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC114 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
NC301 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
NC700 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
NC701 2401-000778 C-AL;220uF,20%,10V,GP,6.3x11,2.5mm,
SC5 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
NC703 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
NC122 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC50L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC50R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC54 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NL101 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL102 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL100 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
SL1 2701-000179 INDUCTOR-AXIAL;33uH,10%,4.2x9.8mm
NL300 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NL301 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NL302 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G
NIC05 AC14-12001G IC;KA78L05,T,-
SCO4 AC14-12001G IC;KA78L05,T,-
AJ59-20150T DECK-CDP;CMS-300,-,-,-,-
SPK PS980E/AMF SPEAKER-SYSTEM;MAX980
