SAMSUNG strives to improve its products at all times. Both the design specifications and these user
instructions are thus subject to change without notice.
Technical Specifications
RADIO
LW(option)
Usable sensitivity 60 dB
SW(option)
Usable sensitivity 40 dB
AM (MW)
Tuning range 522 - 1611KHz
Signal/noise ratio 40 dB
Usable sensitivity 54 dB
Total harmonic distortion 2 %
FM
Tuning range 87.5 - 108MHz
Signal/noise ratio 62 dB
Usable sensitivity 10 dB
Total harmonic distortion 0.3 %
COMPACT DISC PLAYER
Capacity 3 discs
Frequency range 20 Hz - 20 KHz (± 1 dB)
Signal/noise ratio 90 dB (at 1 KHz) with filter
Distortion 0.05 % (at 1 KHz)
Channel separation 74 dB
Disc sizes Diameter: 120 or 80 mm. Thickness: 1.2 mm
TAPE DECK
Frequency range 125 Hz ~ 12 KHz
Signal/noise ratio 40 dB
Channel separation 35 dB
Erasing effect 60 dB
AMPLIFIER
Output power (6 Ω) 70 Watts / Ch RMS, (total harmonic distortion: 10 %)
.............
MAX-B550
100 Watts / Ch RMS, (total harmonic distortion: 10 %)
...........
MAX-B570
Channel separation 50 dB
Signal/noise ratio 75 dB
GENERAL
Dimensions 270 (W) x 332 (H) x 410 (D) mm
