AH92-00896A ASSY PCB-POWER AMP MAX-WL69
SD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
RZD10 0403-000379 DIODE-ZENER UZP12B,12V,11.4-12.6V,1W,DO
RZD11 0403-000379 DIODE-ZENER UZP12B,12V,11.4-12.6V,1W,DO
SZD1 0403-001279 DIODE-ZENER RLZ13B,12.55-13.21V.500MW,LL-3
SZD2 0403-001279 DIODE-ZENER RLZ13B,12.55-13.21V.500MW,LL-3
AQ4 0501-000006 TR-SMALL SIGNAL KSA733C-YTA,PNP,-50V,-50V,-15
AQ9 0501-000006 TR-SMALL SIGNAL KSA733C-YTA,PNP,-50V,-50V,-15
AQ8 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
SQ3 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
SQ4 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
AQ10 0501-000294 TR-SMALL SIGNAL KSA708-YTA,PNP,-80V,-60V,
AQ5 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
AQ6 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
SQ1 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
SQ2 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
AQ7 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
HR7 2001-000028 R-CARBON(S) 100ohm,5%,1/2W,AA,TP,2.4x6.4mm
HR8 2001-000028 R-CARBON(S) 100ohm,5%,1/2W,AA,TP,2.4x6.4mm
AR31 2001-000052 R-CARBON(S) 3.3Kohm,5%,1/2W,AA,TP,2.4x6.4m
SR28 2001-000052 R-CARBON(S) 3.3Kohm,5%,1/2W,AA,TP,2.4x6.4m
SR29 2001-000052 R-CARBON(S) 3.3Kohm,5%,1/2W,AA,TP,2.4x6.4m
SR30 2001-000221 R-CARBON 1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
SR31 2001-000221 R-CARBON 1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR27 2001-000273 R-CARBON 100Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR19 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR7 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR32 2001-000421 R-CARBON 1KOHM,1%,1/8W,AD,TP,1.8*3.2MM
SR33 2001-000421 R-CARBON 1KOHM,1%,1/8W,AD,TP,1.8*3.2MM
HR1L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR1R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR2L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR2R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
SR11 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
SR12 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
SR7 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
SR8 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR30 2001-000508 R-CARBON 220Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR26 2001-000515 R-CARBON 220ohm,5%,1/8W,AA,TP,1.8x3.2mm
AR21 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR24 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR23 2001-000660 R-CARBON 33Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR29 2001-000660 R-CARBON 33Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR17 2001-000660 R-CARBON 33Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR20 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR22 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
HR3L 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR3R 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR10 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR9 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR15 2001-000857 R-CARBON 560ohm,5%,1/8W,AA,TP,1.8x3.2mm
SR16 2001-000857 R-CARBON 560ohm,5%,1/8W,AA,TP,1.8x3.2mm
SR13 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR14 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR34 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR35 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SR18 2001-000977 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8x3.2m
SR19 2001-000977 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8x3.2m
AR6L 2001-000995 R-CARBON 820ohm,5%,1/8W,AA,TP,1.8x3.2mm
AR6R 2001-000995 R-CARBON 820ohm,5%,1/8W,AA,TP,1.8x3.2mm
2001-001000 R-CARBON 82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR32 2001-001088 R-CARBON(S) 1Kohm,5%,1/2W,AA,TP,2.4x6.4mm
RR16 2001-001088 R-CARBON(S) 1Kohm,5%,1/2W,AA,TP,2.4x6.4mm
AR10-1 2003-000008 R-METAL OXIDE(S) 100ohm,5%,1W,AA,TP,3.3x9mm
SR20 2003-000008 R-METAL OXIDE(S) 100ohm,5%,1W,AA,TP,3.3x9mm
SR21 2003-000008 R-METAL OXIDE(S) 100ohm,5%,1W,AA,TP,3.3x9mm
SR26 2003-000428 R-METAL OXIDE(S) 1.5Kohm,5%,1W,AA,TP,3.3x9mm
SR27 2003-000428 R-METAL OXIDE(S) 1.5Kohm,5%,1W,AA,TP,3.3x9mm
AR11-1 2003-000674 R-METAL OXIDE(S) 39ohm,5%,1W,AA,TP,3.3x9mm
SR24 2003-000708 R-METAL OXIDE(S) 47OHM,5%,1W,AA,TP
SR25 2003-000708 R-METAL OXIDE(S) 47OHM,5%,1W,AA,TP
SC8 2201-000146 C-CERAMIC,DISC 100pF,5%,50V,SL,5x3.5mm,5mm,TP
SC9 2201-000146 C-CERAMIC,DISC 100pF,5%,50V,SL,5x3.5mm,5mm,TP
HC2L 2201-000547 C-CERAMIC,DISC 4.7nF,20%, 50V,Y5T,12x4mm,5mm,
HC2R 2201-000547 C-CERAMIC,DISC 4.7nF,20%, 50V,Y5T,12x4mm,5mm,
SC3 2201-000557 C-CERAMIC,DISC 470pF,10%,50V,SL,10.0X4.0mm,5m
SC4 2201-000557 C-CERAMIC,DISC 470pF,10%,50V,SL,10.0X4.0mm,5m
RC101 2201-000565 C-CERAMIC,DISC 47nF,+80% -20% 50V Y5V 12.5*4.
SC12 2201-000629 C-CERAMIC,DISC 5pF,5%,50V,SL,5.0*3.0,2.5mm,TP
SC13 2201-000629 C-CERAMIC,DISC 5pF,5%,50V,SL,5.0*3.0,2.5mm,TP
HC6L 2202-000806 C-CERAMIC,MLC-AXIAL 220pF,10%,50V,Y5P,3.5x19mm,-,T
HC6R 2202-000806 C-CERAMIC,MLC-AXIAL 220pF,10%,50V,Y5P,3.5x19mm,-,T
AC30L 2202-000817 C-CERAMIC,MLC-AXIAL 4.7nF,20%,16V,Y5R,3.5x19,NO US
AC30R 2202-000817 C-CERAMIC,MLC-AXIAL 4.7nF,20%,16V,Y5R,3.5x19,NO US
SC30 2202-000817 C-CERAMIC,MLC-AXIAL 4.7nF,20%,16V,Y5R,3.5x19,NO US
SC31 2202-000817 C-CERAMIC,MLC-AXIAL 4.7nF,20%,16V,Y5R,3.5x19,NO US
SC32 2202-000817 C-CERAMIC,MLC-AXIAL 4.7nF,20%,16V,Y5R,3.5x19,NO US
SC33 2202-000817 C-CERAMIC,MLC-AXIAL 4.7nF,20%,16V,Y5R,3.5x19,NO US
AC100 2202-000854 C-CERAMIC,MLC-AXIAL 47nF,+80-20%,50V,Y5V,3.5x19mm,
SC16 2301-000375 C-FILM,PEF 100nF,10%,50V,11x12.5x6.5,TP
SC17 2301-000375 C-FILM,PEF 100nF,10%,50V,11x12.5x6.5,TP
AC2L 2301-000379 C-FILM,PEF 10nF,10%,50V,6x12x3.5,TP
AC2R 2301-000379 C-FILM,PEF 10nF,10%,50V,6x12x3.5,TP
SC22 2301-000404 C-FILM,PEF 2.2nF,10%,50V,5.5x12x3,TP
SC23 2301-000404 C-FILM,PEF 2.2nF,10%,50V,5.5x12x3,TP
SC10 2401-000240 C-AL 100uF,20%,10V,GP,5*11mm,5mm,TP
SC11 2401-000385 C-AL 10UF,20%,100V,GP,-,6.3X11
SC18 2401-000385 C-AL 10UF,20%,100V,GP,-,6.3X11
SC21 2401-000385 C-AL 10UF,20%,100V,GP,-,6.3X11
HC3L 2401-000419 C-AL 10UF,20%,16V,GP,5*11,5MM,TP
HC3R 2401-000419 C-AL 10UF,20%,16V,GP,5*11,5MM,TP
SC19 2401-000475 C-AL 10uF,20%,50V,GP,5*11,5mm,TP
SC20 2401-000475 C-AL 10uF,20%,50V,GP,5*11,5mm,TP
SC35 2401-000759 C-AL 220NF,20%,50V,GP,5X11MM,5MM,TP
AC14 2401-001361 C-AL 470UF,16V,BP,10*20MM,5MM
AC17 2401-001895 C-AL 100uF,20%,16V,GP,6.3*11,5MM,TP
AC15 2401-001912 C-AL 1uF,20%,50V,GP,5*11,5mm,TP
SC5 2401-001954 C-AL 4.7UF,20%,50V,GP,5*11,5MM,TP
SC6 2401-001954 C-AL 4.7UF,20%,50V,GP,5*11,5MM,TP
HC1 2401-001975 C-AL 47uF,20%,16V,GP,5*11,5mm,TP
HC2 2401-001975 C-AL 47uF,20%,16V,GP,5*11,5mm,TP
HC1L 2401-002180 C-AL 2.2uF,20%,50V,GP,5*11,5mm,TP
HC1R 2401-002180 C-AL 2.2uF,20%,50V,GP,5*11,5mm,TP
HR6L 2701-000114 INDUCTOR-AXIAL 10uH,10%,2.5x3.4mm,LA02TB100K
HR6R 2701-000114 INDUCTOR-AXIAL 10uH,10%,2.5x3.4mm,LA02TB100K
H/SINK TO AH39-20538A LEAD-CONNECTOR ASSY -,5051,5264,3P
AIC1 1201-001712 IC-POWER AMP 442-050,SIP,14P,233MIL,DUAL,30
SIC2 1201-001713 IC-POWER AMP STK412-090,SIP,18P,251MIL,DUAL
SR22 2009-001081 R-METAL PLATE 0.22OHM,5%,7W,CL,BK,26*5*2
SR23 2009-001081 R-METAL PLATE 0.22OHM,5%,7W,CL,BK,26*5*2
SC14 2401-000230 C-AL 100uF,20%,100V,GP,10x20mm,5mm,
SC15 2401-000230 C-AL 100uF,20%,100V,GP,10x20mm,5mm,
ARY1 3501-001197 RELAY-MINIATURE OSA-SS-212DM3
SRY1 3501-001197 RELAY-MINIATURE OSA-SS-212DM3
SPK 3716-001132 TERMINAL-BLOCK P40420421P-RED,
W-SPK 3716-001163 TERMINAL-BLOCK P4042042QP-BLUE,7A
AD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
AD2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
HD1 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
HD2 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
AQ1L 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
AQ1R 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
AQ2L 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
AQ2R 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
AQ1 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
AR1L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR1R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR5L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR5R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR2L 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR2R 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR4L 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR4R 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR8L 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR8R 2001-000864 R-CARBON 56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR18 2001-000977 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8x3.2m
HR4L 2001-000977 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8x3.2m
HR4R 2001-000977 R-CARBON 8.2KOHM,5%,1/8W,AA,TP,1.8x3.2m
AR12L 2003-000689 R-METAL OXIDE(S) 4.7ohm,5%,1W,AA,TP,3.3x9mm
AR12R 2003-000689 R-METAL OXIDE(S) 4.7ohm,5%,1W,AA,TP,3.3x9mm
AC12L 2201-000368 C-CERAMIC,DISC 220pF,10%,50V,SL,6.5*3.0,5mm,T
AC12R 2201-000368 C-CERAMIC,DISC 220pF,10%,50V,SL,6.5*3.0,5mm,T
AC1L 2201-000557 C-CERAMIC,DISC 470pF,10%,50V,SL,10.0X4.0mm,5m
AC1R 2201-000557 C-CERAMIC,DISC 470pF,10%,50V,SL,10.0X4.0mm,5m
AC4L 2201-000629 C-CERAMIC,DISC 5pF,5%,50V,SL,5.0*3.0,2.5mm,TP
AC4R 2201-000629 C-CERAMIC,DISC 5pF,5%,50V,SL,5.0*3.0,2.5mm,TP
AC7L 2301-000375 C-FILM,PEF 100nF,10%,50V,11x12.5x6.5,TP
AC7R 2301-000375 C-FILM,PEF 100nF,10%,50V,11x12.5x6.5,TP
AC3L 2401-000240 C-AL 100uF,20%,10V,GP,5*11mm,5mm,TP
AC3R 2401-000240 C-AL 100uF,20%,10V,GP,5*11mm,5mm,TP
AC5 2401-000325 C-AL 100uF,20%,35V,GP,8*11.5,5MM,TP
AC6 2401-000325 C-AL 100uF,20%,35V,GP,8*11.5,5MM,TP
AC32 2401-000419 C-AL 10UF,20%,16V,GP,5*11,5MM,TP
AC18 2401-000847 C-AL 220uF,20%,35V,GP,10x12mm,5mm,T
AC31L AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
AL1L AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
AL1R AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
AL2R AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
SL1 AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
SL2 AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
SL3 AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
SL4 AH27-90001A COIL-SPRING ,2.2UH,-,-,SPRING
AH61-00529A BRACKET-H/SINK L MAX-L65,SECC 1.0T,-,-,-
AH61-00530A BRACKET-H/SINK R MAX-L65,SECC 1.0T,-,-,-
AH62-00037B HEAT SINK-M MAX-ZL65,AL,-,100,-,-,-,-
AH62-30127B HEAT-SINK AL2M/M
AIC2 1203-001653 IC-VOLTAGE REQULATOR 4959,MULTIWATT,15P,700MIL,PLAS
ACW2-1 3711-000658 CONNECTOR-HEADER BOX,12P,1R,2.5mm,STRAIGHT,SN
ACW10 3711-000820 CONNECTOR-HEADER 5267-02A 2P ST
HCW1 3711-001062 CONNECTOR-HEADER BOX,6P,1R,2mm,STRAIGHT,SN
ACW1-1 3711-001102 CONNECTOR-HEADER BOX,7P,1R,2mm,STRAIGHT,SN
RCW11 3711-003107 CONNECTOR-HEADER BOX,3P,1R,2.5MM,-,BRASS
Location no Code no. Description Specifiation Remarks Location no Code no. Description Specifiation Remarks
Samsung Electronics 3-13
