AH92-00898A ASSY PCB-MAIN MAX-WL69
AD3 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
AD4 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
AD5 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
FD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
FD2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
FD5 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD2 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD3 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD4 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
JD5 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
RD4 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
RD1 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
RD2 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
RD3 0402-000127 DIODE-RECTIFIER 1N4002,100V,1A,DO-41
FZD1 0403-000315 DIODE-ZENER UZ10BH,10V,10.0-10.6V,500mW
RZD4 0403-000354 DIODE-ZENER UZ5.1B,5.1V,4.8-5.4V,500mW,
RZD3 0403-000365 DIODE-ZENER UZ6,8BSB,6.8V,6.52-6.79
RZD1 0403-000570 DIODE-ZENER UZP18B,18V,16.9-19.1V,1W
RZD2 0403-000570 DIODE-ZENER UZP18B,18V,16.9-19.1V,1W
JQ2L 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ2R 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ3L 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
JQ3R 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
RQ2 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
RQ3 0501-000010 TR-SMALL SIGNAL KSC1008-YTA,NPN,80V,60V,700mA,
RQ1 0501-000294 TR-SMALL SIGNAL KSA708-YTA,PNP,-80V,-60V,
JQ14 0501-000369 TR-SMALL SIGNAL KSC2331-Y-TA ,80V,60V,700mA
FQ3 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
FQ4L 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
FQ4R 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
FQ6 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ10L 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ10R 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ12 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ5 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ9L 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ9R 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
JQ4L 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
JQ4R 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
JQ6L 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
JQ6R 0501-000407 TR-SMALL SIGNAL KSD471-YTA,40V,30V,1A,800m TP
JQ13 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W
FQ2L 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
FQ2R 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
JQ1L 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
JQ1R 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
FQ1 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
FQ5 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
JQ11 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
JQ15 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
JQ17 0504-001003 TR-DIGITAL KSR2003TA,300mW,22K-22Kohm
FR27L 2001-000008 R-CARBON 15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR27R 2001-000008 R-CARBON 15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR31L 2001-000008 R-CARBON 15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR31R 2001-000008 R-CARBON 15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR40 2001-000023 R-CARBON 47ohm,5%,1/4W,AA,TP,2.4x6.4mm
JR21 2001-000034 R-CARBON 220ohm,5%,1/4W,AA,TP,2.4x6.4mm
FR25L 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR25R 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR27L 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR27R 2001-000241 R-CARBON 1.5Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR24L 2001-000258 R-CARBON 1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR24R 2001-000258 R-CARBON 1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR5L 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
JR5R 2001-000281 R-CARBON 100ohm,5%,1/8W,AA,TP,1.8x3.2mm
FR10L 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR10R 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR28 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR10 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR11 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR18L 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR18R 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR22L 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR22R 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR41 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR44 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR10 2001-000290 R-CARBON 10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR3L 2001-000302 R-CARBON 10ohm,5%,1/8W,AA,TP,1.8x3.2mm
JR3R 2001-000302 R-CARBON 10ohm,5%,1/8W,AA,TP,1.8x3.2mm
JR14 2001-000319 R-CARBON 120Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR16L 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR16R 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR30L 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR30R 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR8L 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR8R 2001-000331 R-CARBON 12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR32 2001-000362 R-CARBON 150ohm,5%,1/8W,AA,TP,1.8x3.2mm
FR26L 2001-000411 R-CARBON 18Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR26R 2001-000411 R-CARBON 18Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR22 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR31 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR24L 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR24R 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR32L 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR32R 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR9 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR14 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR7 2001-000429 R-CARBON 1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR6L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR6R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR7L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR7R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR1L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR1R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR17L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR17R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR2L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR2R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR34L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR34R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR35L 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR35R 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR46 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR42 2001-000456 R-CARBON 2.2ohm,5%,1/4W,AA,TP,2.4x6.4mm
FR3 2001-000515 R-CARBON 220ohm,5%,1/8W,AA,TP,1.8x3.2mm
FR4 2001-000515 R-CARBON 220ohm,5%,1/8W,AA,TP,1.8x3.2mm
FR1L 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR1R 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR14 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR19 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR2L 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR2R 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR21 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR26L 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR26R 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR15 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR9 2001-000522 R-CARBON 22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR13 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR15 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR19R 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR29L 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR29R 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR36L 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR36R 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR38 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR43 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR12 2001-000591 R-CARBON 3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR7L 2001-000613 R-CARBON 3.9Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR7R 2001-000613 R-CARBON 3.9Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR5 2001-000613 R-CARBON 3.9Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR16 2001-000708 R-CARBON 39ohm,5%,1/8W,AA,TP,1.8x3.2mm
FR12L 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR12R 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR23L 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR23R 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR20L 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR20R 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR33L 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR33R 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR39 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR6 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR11 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR13 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR6 2001-000734 R-CARBON 4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR20 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR12 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR23L 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR23R 2001-000773 R-CARBON 470Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR18 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR29 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR25L 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR25R 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
JR37 2001-000786 R-CARBON 47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR5L 2001-000802 R-CARBON 5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR5R 2001-000802 R-CARBON 5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR28L 2001-000802 R-CARBON 5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR28R 2001-000802 R-CARBON 5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR4 2001-000802 R-CARBON 5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR13L 2001-000857 R-CARBON 560ohm,5%,1/8W,AA,TP,1.8x3.2mm
FR13R 2001-000857 R-CARBON 560ohm,5%,1/8W,AA,TP,1.8x3.2mm
JR4L 2001-000890 R-CARBON 6.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR4R 2001-000890 R-CARBON 6.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
JR8 2001-000890 R-CARBON 6.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR17L 2001-001000 R-CARBON 82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR17R 2001-001000 R-CARBON 82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR2 2001-001153 R-CARBON(S) 47ohm,5%,1/2W,AA,TP,2.4x6.4mm
RR3 2001-001153 R-CARBON(S) 47ohm,5%,1/2W,AA,TP,2.4x6.4mm
JSR2L 2103-000248 VR-SEMI 200Kohm,30%,1/10W,TOP
JSR2R 2103-000248 VR-SEMI 200Kohm,30%,1/10W,TOP
JSR1L 2103-000492 VR-SEMI 5Kohm,30%,1/10W,TOP
JC3L 2201-000300 C-CERAMIC,DISC 1nF,20%,50V,Y5T,4x4mm,5mm,TP
JC3R 2201-000300 C-CERAMIC,DISC 1nF,20%,50V,Y5T,4x4mm,5mm,TP
FC22L 2201-000368 C-CERAMIC,DISC 220pF,10%,50V,SL,6.5*3.0,5mm,T
FC22R 2201-000368 C-CERAMIC,DISC 220pF,10%,50V,SL,6.5*3.0,5mm,T
Location no Code no. Description Specifiation Remarks Location no Code no. Description Specifiation Remarks
3-14 Samsung Electronics
