PREPARING THE INSTALLATION
Air Conditioner and Accessories
The following accessories are supplied with the air conditioner.
Accessories in the Outdoor Unit Case
 MH040FX  A2B/MH040FX  A2C/MH050FX  A2B/MH050FX  A2C/MH060FX  A3B/MH18VF1X/MH19VF1X
3-wire
Power Cable
(option)
2-wire
Assembly Cable
(option)
Drain Plug
Energy Label
Rubber Leg Flare Bolt
(Nut 1/2”, Bolt 3//8”)
(except MH040FX

A2B)
Installation Manual
Attach Energy Label to the outdoor unit properly when installing.
 MH070FX  A4B / MH080FX  A4B
3-wire
Power Cable
(option)
2-wire
Assembly Cable
(option)
Drain Plug
Energy Label
Rubber Leg Flare Nuts, 6.35mm
outer pipe diameter
Flare Nuts, 9.52mm
outer pipe diameter
Flare Bolt
(Nut 1/2”, Bolt 3/8”)
Installation Manual
Attach Energy Label to the outdoor unit properly when installing.

The 3-wire power cable and the 2-wire assembly cable are optional. If these cables are not supplied, use the
standard cable approved by IEC standard.
Please, check “Connecting the Cables to the Outdoor Unit” section.
