Disassembly and Reassembly
Samsung Electronics4-8
No Parts Procedure Remark
1
Front Grille
&
Filter
1) Open the Front-Grille by pushing the tabs
on the Grille.
You must give attention when
disassembling the Front-Grille and
must check the safety clips have
been installed. If you don’t ensure
them, the Front Grille will drop
suddenly and you will be hurt.
2) Detach the Front Grille.
(1) Remove the safety clips.
(2) Open the Front Grille about 45˚ and
pull it forward.
3) Pull out the Air-Filter.
4-1-3 MH✳✳✳FKEA
24296A(1)_1 11/11/05 5:03 PM Page 4-8
To Next Page
