5-36Samsung Electronics
Exploded Views and Parts List
■
Parts List
Q'TY
No.
Code No. Description Specification SA/SNA
1 DB90-01711E ASS’Y CABINET-FRONT ASS’Y 1 SNA
2 DB63-00847A GUARD FAN SC-90073T 1 SA
3 DB90-01713A ASS’Y-CABI SIDE LF ASS’Y1SA
3-1 DB64-00982A CABINET-SIDE LF SECC-P 1 SA
3-2 DB64-00992A HANDLE-LF PP 1 SA
4 DB63-01172A COVER-CONTROL ABS 1 SA
5 DB90-03097A ASS’Y CABINET-SIDE ASS’Y 1 SNA
6 DB90-01681D ASS’Y BASE OUT ASS’Y 1 SNA
7 DB61-03162A BRACKET-VALVE PAINT SECC-P 1 SNA
8 DB94-01327A ASS’Y PARTITION ASS’Y 1 SNA
9 DB61-01644A BRACKET MOTOR SECC-P 1 SA
10 DB61-02238A BRACKET-SUPPORT BASE SECC-P 3 SA
11 DB31-00431A MOTOR FAN-BLDC SIC-52FV-F726-1 1 SC
12 DB67-00397A FAN PROPELLER AS+GF 20% 1 SA
13 DB60-30004A SCREW-MACHINE M6,ZPC(WHT) 1 SNA
14 DB93-04421A ASS’Y CONTROL OUT ASS’Y1SA
14-1 DB61-02249A CASE CONTROL-COVER ABS 1 SA
14-2 DB93-04347C ASS’Y PCB MAIN-INV ASS’Y1SA
14-3 DB62-03155A HEAT SINK AL 1 SA
14-4 DB93-04906A ASS’Y PCB SUB-EMI ASS’Y 1 SNA
14-5 DB93-04330B ASS’Y PCB MAIN ASS’Y1SA
14-6 DB62-02250A CASE CONTROL-BASE ABS 1 SNA
14-7 DB70-00728A PLATE-CONTROL OUT UPPER SGCC-M 1 SNA
14-8 DB70-00727A PLATE-CONTROL OUT MAIN SGCC-M 1 SNA
14-9 DB65-00181D TERMINAL BLOCK BLK 1 SC
14-10 DB65-00181F TERMINAL BLOCK BLK 1 SC
14-11 DB95-01180A ASS’Y-TERMINAL BLOCK ASS’Y1SC
14-12 DB93-04422A ASS’Y PCB DISPLAY ASS’Y1SA
14-13 DB61-01097A HOLDER-WIRE CLAMP ABS 2 SA
15 DB95-01172A ASS’Y COMP PART ASS’Y 1 SNA
15-1 DB63-00763A GROMMET ISOLATOR NR35 3 SA
15-2 DB60-30028A SCREW-HEX ZPC(WHT) 3 SA
15-3 6021-001142 NUT-HEXAGON FLANGE M5,ZPC(YEL) 1 SA
15-4 DB63-00762A COVER TERMINAL GE-NORYL 1 SA
15-5 6021-001142 GASKET EPDM 1 SA
15-6 G4A110LUAER COMPRESSOR BLDC 1 -
16 DB96-06888A ASS’Y COND ASS’Y 1 SNA
17 DB96-06894A ASS’Y-4 WAY VALVE ASS’Y 1 SNA
18 DB96-06893A ASS’Y-VALVE ASS’Y 1 SNA
