5-38Samsung Electronics
Exploded Views and Parts List
■
Parts List
Q'TY
SA/SNANo. Code No. Description Specification
MH052FXEA2A
MH18VV1X
MH19VV1X
MH060FXEA3A
1 DB90-01146E ASS'Y CABINET FRONT ASS'Y 1 1 SA
1-1 DB63-00838A GUARD FAN PP,SC-90073R 1 1 SA
2 DB90-03278A ASS'Y BASE OUT ASS'Y 1 1 SNA
3 DB67-00142A FAN PROPELLER PP 1 1 SA
4 DB31-00264D MOTOR FAN SGCC-M 1 1 SA
5 DB61-00686A BRACKET MOTOR ASS'Y 1 1 SA
6 DB94-01326A ASS'Y PARTITION ASS'Y 1 1 SNA
7 DB96-06860A ASS'Y CONDENSER ASS'Y 1 1 SA
8 DB61-00821B GUIDE SCREEN P.E.H 100% 1 1 SC
9 DB90-03096A ASS'Y CABINET SIDE ASS'Y 1 1 SA
10 DB90-40176B ASS'Y COVER CONTROL ASS'Y 1 1 SA
11 DB90-03275A ASS'Y CABINET UP ASS'Y 1 1 SA
12 DB63-00692A GUARD CONDENSER SECC-P 1 1 SA
13 G4B135LUAEH ROTARY COMPRESSOR
BLDC PERMANENT MAGNETIC MOTOR
1-SA
G8T200FUAEW ROTARY COMPRESSOR
BLDC PERMANENT MAGNETIC MOTOR - 1
SA
13-1 DB63-00763A GROMMET-ISOLATOR NR 3 3 SNA
14 DB99-06846A ASS'Y VALVE 4-WAY ASS'Y 1 - SA
DB96-06843A ASS'Y VALVE 4-WAY ASS'Y - 1 SA
15 DB99-06845A ASS'Y VALVE ASS'Y 1 - SA
DB96-06842A ASS'Y VALVE ASS'Y - 1 SA
16 DB93-04420D ASS'Y CONTROL OUT ASS'Y 1 - SA
DB93-04420C ASS'Y CONTROL OUT ASS'Y - 1 SA
16-1 DB93-04266H ASS'Y PCB MAIN ASS'Y 1 - SA
DB93-04266G ASS'Y PCB MAIN ASS'Y - 1 SA
16-2 DB61-02974A CASE CONTROL-COVER ASS’Y11SA
16-3 DB62-04626A HEAT SINK ABS 1 1 SNA
16-4 DB93-04745B ASS’Y PCB EMI ASS’Y 1 1 SNA
16-5 DB61-02973A CASE CONTROL-BASE AL 1 1 SA
16-6 DB70-00730A
PLATE-CONTROL OUT UPPER
ABS 1 1 SNA
16-7 DB70-00729A PLATE-CONTROL OUT MAIN SGCC-M 1 1 SNA
16-8 DB65-00181D TERMINAL BLOCK BLK 1 1 SC
16-9 DB65-00181E TERMINAL BLOCK BLK - 1 SC
DB65-00181F TERMINAL BLOCK BLK 1 - SC
16-10 DB95-01180A ASS’Y-TERMINAL BLOCK ASS’Y11SC
16-11 DB93-04422A ASS’Y PCB DISPLAY ASS’Y11SA
16-12 DB61-01097A HOLDER-WIRE CLAMP ABS 2 2 SA
17 DB27-00042A REACTOR 5MH±5%,40.0±5V 1 1 SA
18 DB32-00175B THERMISTOR CONDENSER 103AT,204CTB 1 1 SA
19 DB32-00176A THERMISTOR 103AT,204CTB 1 1 SA
