5-40Samsung Electronics
Exploded Views and Parts List
■
Parts List
Q'TY
SA/SNA
No. Code No. Description Specification
1 DB90-03287A ASS'Y CABINET FRONT PAINT 1 1 SNA
1-1 DB63-00831A GUARD FAN 1 1 SA
2 DB90-03278C ASS'Y BASE OUT 1 1 SNA
3 DB67-00438B FAN PROPELLER 1 1 SA
4 DB31-00429A MOTOR FAN 1 1 SA
5 DB61-20094C BASE MOTOR 1 1 SC
6 DB94-01352A ASS'Y PARTITION 1 1 SNA
7 DB96-06874A ASS'Y COND 1 1 SNA
8 DB60-70002A PIN SCREEN 1 1 SNA
9 DB90-03134A ASS'Y CABINET SIDE 1 1 SNA
10 DB90-03292A ASS'Y COVER CONTROL 1 1 SNA
11 DB90-03275A ASS'Y CABINET-UP 1 1 SNA
12 DB63-00758A GUARD COND 1 1 SA
13 G8T260FUAEW ROTARY COMPRESSOR 1 1 SA
13-1 DB63-00815A GROMMET-ISOLATOR 3 3 SNA
14 DB96-06883A ASS'Y 4-WAY VALVE 1 1 SNA
15 DB96-06882A ASS'Y VALVE 1 1 SNA
15-1 DB96-06878A ASS'Y TUBE EEV A 1 1 SNA
15-2 DB96-06879A ASS'Y TUBE EEV B 1 1 SNA
15-3 DB96-06880A ASS'Y TUBE EEV C 1 1 SNA
15-4 DB96-06881A ASS'Y TUBE EEV D 1 1 SNA
16 DB93-04420A ASS'Y CONTROL OUT - 1 SA
DB93-04420B ASS'Y CONTROL OUT 1 - SA
16-1 DB93-04266E ASS'Y PCB MAIN 1 1 SA
DB93-04266F ASS'Y PCB MAIN 1 - SA
16-2 DB61-02974A CASE CONTROL-COVER ASS’Y11SA
16-3 DB62-04626A HEAT SINK ABS 1 1 SNA
16-4 DB93-04745A ASS’Y PCB EMI ASS’Y 1 1 SNA
16-5 DB61-02973A CASE CONTROL-BASE AL 1 1 SA
16-6 DB70-00730A PLATE-CONTROL OUT UPPER ABS 1 1 SNA
16-7 DB70-00737A PLATE-CONTROL OUT MAIN SGCC-M 1 1 SNA
16-8 DB65-00181D TERMINAL BLOCK BLK 1 1 SC
16-9 DB65-00181F TERMINAL BLOCK BLK 2 2 SC
16-10 DB95-01180A ASS’Y-TERMINAL BLOCK ASS’Y11SC
16-11 DB93-04422A ASS’Y PCB DISPLAY ASS’Y11SA
16-12 DB61-01097A HOLDER-WIRE CLAMP ABS 2 2 SA
17 DB27-00043A REACTOR 1 1 SA
18 DB32-00175B THERMISTOR COND 1 1 SC
19 DB32-00176C
THERMISTOR WIRE OUT/DISCHARGE 11SC
MH070FXEA4A MH080FXEA4A
ASS'Y
PP,SC-90073R
ASS'Y
PP(LUPOL LW4302)
SGCC-M
ASS'Y
ASS'Y
ASS'Y
P.E.H 100%
ASS'Y
ASS'Y
ASS'Y
SECC-P
BLDC INVERTER
NR
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
ASS'Y
5mH±20%,34.0±5%
103AT,204CTB
103AT,204CTB
