PCB Diagram
!
Power N
@
Power L
#
BLDC Fan : YAW396-07V(WHT)
$
Main PCB Connector : SMW200-07(WHT)
%
Power Relay
^
Comp. Connector Wire
&
Reactor Connector Wire
■ MH040FXEA2A(INVERTER)
^
$ # % ! @&
