PCB Diagram
8-14Samsung Electronics
!
Power N
@
Power L
#
BLDC FAN
$
AC FAN
%
Communication 485
^
COND/OLP Temperature Sensor
&
DIS/OUT Temperature Sensor
*
EEV Connector
(
Comp. Connector Wire
)
Reactor Connector Wire
■ MH052FXEA2A/MH060FXEA3A/MH070FXEA4A/MH080FXEA4A/MH18VV1X/MH19VV1X
The red number connecter is not used.
