Exploded Views and Parts List
5-14Samsung Electronics
■
Parts List(cont.)
Q'TY
SA/SNA
No. Code No. Description Specification
MH023FVEA
MH026FVEA
MH18VV1-09
MH19VV1-07
MH035FVEA
MH19VV1-12
MH052FVEA
1 DB92-00927G ASS'Y PANEL FRONT ASS'Y HALF MIRROR 1 - SNA
DB92-00926D ASS'Y PANEL FRONT ASS'Y HALF MIRROR - 1 SNA
1-1 DB64-01633A PANEL FRONT HIPS,EMPIRE SILVER 1 - SA
DB64-01638A PANEL FRONT HIPS,EMPIRE SILVER - 1 SA
1-2 DB63-01593A FILTER-PRE PP,GRAY 2 - SA
DB63-01594A FILTER-PRE PP,GRAY - 2 SA
1-3 DB64-01634A PANEL-MID HIPS,EMPIRE SILVER 1 - SA
DB64-01639A PANEL-MID HIPS,EMPIRE SILVER - 1 SA
1-4 DB66-01152A LINK-GRILLE POM,WHITE 1 1 SA
1-5 DB66-01156A GEAR-RACK POM,WHITE 1 1 SA
1-6 DB66-01155A GEAR-PINION POM,WHITE 1 1 SA
1-7 DB31-00369B MOTOR STEP ASS'Y 1 1 SA
1-8 DB61-03156A HOLDER-WIRE PC,WHITE - 3 SA
1-9 DB66-01176A LINK-SUPPORT POM,WHITE 4 4 SA
1-10 DB61-03139A SPRING ETC-GRILLE STS 2 2 SA
1-11 DB63-01630A COVER-DISPLAY ABS-FR(17) 1 1 SA
1-12 DB93-04452B ASS'Y DISPLAY ASS'Y 1 1 SA
1-13 DB61-02910A FRAME-GRILLE ASS'Y 1 1 SA
1-14 DB64-01724A WINDOW-MIRROR ACRYL 1 - SNA
DB64-01725A WINDOW-MIRROR ACRYL - 1 SNA
2 DB94-01237A ASS'Y TRAY DRAIN ASS'Y 1 - SA
DB94-01245A ASS'Y TRAY DRAIN ASS'Y - 1 SA
2-1 DB63-01578A TRAY DRAIN ASS'Y 1 - SA
DB63-01581A TRAY DRAIN ASS'Y - 1 SA
2-2 DB61-02908A BLADE-H ABS, EMPIRE SILVER 1 - SA
DB61-02914A BLADE-H ABS, EMPIRE SILVER - 1 SA
2-3 DB61-01636A BLADE-V PP 2 - SA
DB61-01976A BLADE-V PP - 2 SA
2-4 DB73-00180A RUBBER-CAP DRAIN GUM-EPM 1 1 SNA
2-5 DB94-00458B ASS'Y DRAIN-HOSE ASS'Y 1 1 SA
2-6 DB31-00371A MOTOR STEP ASS'Y 1 - SA
DB31-00370A MOTOR STEP ASS'Y - 1 SA
3 DB63-00844D COVER-TERMINAL HIPS,V0 1 - SA
DB63-01063C COVER-TERMINAL HIPS,V0 - 1 SA
4 DB63-00850A COVER-BEARING ABS,BLACK 1 - SNA
DB63-01065A COVER-BEARING ABS,BLACK - 1 SNA
5 DB96-03149A ASS'Y EVAP-SUPPORT RH ASS'Y 1 - SA
DB96-03817A ASS'Y EVAP-SUPPORT RH ASS'Y - 1 SA
6 DB93-04636A ASS'Y CONTROL IN ASS'Y 1 - SNA
DB93-04664A ASS'Y CONTROL IN ASS'Y - 1 SNA
