ΒΣΥΤͽΚΤΥ
Draw#
(Section-No.)
Part Code Description Location SNA
SA : Service Available, SNA : Service not Available
7.2-5-2 JC61-01154A BRACKET-P-MOTOR M2048 SNA
7.2-5-3 JC66-00804A GEAR-RDCN 139/83 G0383 SA
7.2-5-5 JC72-00825A PMO-IMPELLER_DRV K4023 SNA
7.2-6
7.4-0
JC97-02175A MEA UNIT-FRAME PAPER PATH B0101 SA
6003-000196 SCREW-TAPTITE;PWH,+,B,M3,L10,NI SA
7.4-3 JB61-00107A 0PRING ETC-LEVER SENSOR;SF-430,SUS304,0. Z4209 SA
7.4-12 JC33-00015B SOLENOID-MP_R2;-,SCX-4720F,DC24V,-,-,-,- S8014 SA
7.4-18 JC61-00583A HOLDER-PTL;ML-1400,ABS,-,-,-,BLK,- H4041 SA
7.4-14 JC61-00588A BUSH-M-TR L;ML-1400,POM(M90-44),-,-,-,BL K2886 SA
7.4-21 JC61-01151A HOUSING-M-PICK_U P2067 SNA
7.4-1 JC61-01161A GUIDE-M-PAPER PATH G2069 SA
7.4-22 JC61-01173A HOUSING-M-PICK_UP B P2068 SNA
7.4-16 JC61-70940A SPRING ETC-TR(12) Z4277 DNA
7.4-7 JC63-00623A GROUND-P-THV W3078 SNA
7.4-6 JC63-00624A GROUND-P-ZENER W3077 SNA
7.4-5 JC63-00625A GROUND-P-VARISTOR W3076 SNA
7.4-8 JC63-00626A GROUND-P-SAW W3079 SNA
7.4-17 JC66-00725A ROLLER-TRANSFER;SCX-4100,NBR FOAM,¾å15,2 T3014 SA
7.4-13 JC66-00809A GEAR-FEED 35/19 F6071 SA
7.4-24 JC66-00811A CAM-M-PICK_UP P2042 SA
7.4-25 JC66-00813A GEAR-TRANSFER G0448 SA
7.4-2 JC66-00814A LEVER-ACTUATOR FEED SENSOR E7006 SA
7.4-10 JC66-00815A LEVER-M-KICKER P/U R1120 SNA
7.4-20 JC66-00829A SHAFT-P-PICK_UP P2160 SA
7.4-19 JC70-00307A IPR-P-EARTH TRANSFER;ML-1400,SECC,-,1.0T K3367 SA
7.4-4 JC70-10232A IPR-PLATE SAW K3377 SA
7.4-15 JC72-00102A PMO-BUSHING_TR(L);SF-5100,POM ,B K3856 SA
7.4-23 JC73-00211A RUBBER-PICK_UP P2148 SA
7.4-11 JC97-02179A MEA UNIT-PICK UP GEAR P2093 SA
7.4-11-3 6107-001167 SPRING-CS D4089 SA
7.4-11-2 JC66-00802A GEAR-PICK_UP A P2057 SA
JC66-00803A GEAR-PICK_UP B P2056 SA
7.4-9 JC97-02217A MEA UNIT-HOLDER_PAD P0015 SA
7.4-9-3 JC61-01169A HOLDER-M-PAD H4029 SA
7.4-9-1 JC61-70911A SPRING ETC-EXIT ROLL FD;ML-165,SUS304 WP Z4137 SA
7.4-9-2 JC69-00846A PAD-FRICTION R1049 SNA
7.2-2 JC97-02218A MEA UNIT-PLATE KNOCK_UP K3602 SA
7.2-2-1 JC61-01158A PLATE-M-KNOCK_UP K5002 SA
7.2-2-2 JC66-00720A SHAFT-P-CORE;ML-1750,SECC 1.6T,220,-,-,- P2158 SNA
7.2-2-3 JC72-01004A PMO-IDLE KNOCK UP MP K5006 SA
7.2-2-4 JC74-00011A MPR-PAD KNOCK UP MP K5007 SNA
7.2-9 JG66-40003A GEAR-PINION;SF4000,POM,WHT,M1,Z1 G0369 SA
7.1-6 JC96-03352B ELA UNIT-DEVE INITIAL T2060 SNA
0105-001032 PAPER-ART;75g,W210,-,WHITE,HANSO SNA
0203-001189 TAPE-ACETATE;#810,T0.05,W12,L65000,NTR SNA
6902-000455 BAG CONDUCTIVE SA
JC68-00274A LABEL(R)-RIBBON;SF-5100,100,-,-, SNA
JC68-01493A MANUAL-CARD PROTECTION SNA
JC68-10914D LABEL(P)-SERIAL NO;ML-85,ART,70X SNA
JC96-03354A ELA UNIT-DEV KIT 1K SNA
0201-001183 ADHESIVE-AA;ARON ALPHA #202F,NTR,100,20G SNA
0205-001059 GREASE-BEARING;PETAMO GHV 133,BE SNA
0205-001067 GREASE-GRAPHITE;NYOGEL 756G,HYDR SNA
0205-001088 GREASE-BEARING;HANARL FL-955,NOISE DAMPI SNA
