Samsung ML-1600 Series - Service-BOM Parts List

΁ΒΣΥΤͽΚΤΥ
Draw#
(Section-No.)
Part Code Description Location SNA
7.1-7
7.3-0
JC96-03401A ELA HOU-FUSER 220V F4038 SA
7.3-29 JC63-00637A COVER-M-FUSER-DUMMY Z2194 SNA
7.3-31 JC63-00638A COVER-M-LAMP-R L1015 SNA
7.3-30 JC63-00639A COVER-M-LAMP-L L1014 SNA
7.3-11 JC66-00564A GEAR-FUSER, Z37;ML-1710,HTN51G35HSL,0.8, F4094 SA
7.3-9 JC66-00600A ROLLER-PRESSURE P6014 SA
7.3-10 JC66-00601A ROLLER-HEAT H2010 SA
7.3-26 JC66-00801A GEAR-EXIT_DR38/25 E4039 SNA
7.3-4 JC66-00810A GEAR-EXIT_DRV17 E4038 SNA
7.3-15 JC66-00824A ROLLER-M-EXIT MAIN R1083 SNA
7.3-33 JC66-00826A ROLLER-EXIT F/DOWN E4159 SA
7.3-16 JC66-00830A ROLLER-M-EXIT FR R1084 SNA
7.3-7 JC66-10901A BEARING-PRESSURE/R;ML-165,PPS,5,-,14.8 P6004 SA
7.3-34 JC67-00085A CAP-M-THERMO H4087 SNA
JC68-00407A LABEL(R)-HV FUSER;ML-6060,PVC,-,220V,- L0018 SNA
JC68-30928D LABEL(P)-CAUTION, HOT_FUSER L0035 SNA
0105-001032 PAPER-ART;75g,W210,-,WHITE,HANSO SNA
0205-001003 GREASE-BEARING;NYOGEL788,DAMPING SNA
7.3-19 1404-001298 HERMISTOR-NTC;7KOHM,-,3370K,0.3MW/C,-,- W3071 SA
7.3-14 4713-001202 LAMP-HALOGEN K2297 SA
6003-000196 SCREW-TAPTITE;PWH,+,B,M3,L10,NI SA
6003-000269 SCREW-TAPTITE;BH,+,S,M3,L6,ZPC(Y F1017 SA
6003-000282 SCREW-TAPTITE;BH,+,B,M3,L8,ZPC(BLK),SWCH SA
7.3-27 6031-001051 WASHER-PLAIN;M4,ID4.1,OD7.0,T0.1 S2004 SNA
7.3-32 6044-000001 RING-CS;ID3,OD3,T0.25,BLACK,SUS304 D4088 SNA
7.3-18
7.3-28
6107-001163 SPRING-CS;SUS304-WPB,-,PI0.4,D3.9,L13,-, D4086 SA
7.3-6
7.3-17
6107-001168 SPRING-CS D4085 SNA
7.3-22 JC39-00403A CBF HARNESS-FUSER(110V) H1085 SA
7.3-21 JC39-00404A CBF HARNESS-FUSER JOINT H1089 SA
7.3-20 JC47-00005B THERMOSTAT-150 K4279 SA
7.3-23 JC61-00064A SPRING-CLAW;ML-5200A,SUS 304 WPB B2031 SNA
7.3-24 JC61-00584A HOLDER-M-PLATE CLAW;ML-1400,PET+GF30%,-, H4031 SA
7.3-12 JC61-00589A BUSH-M-HR L;ML-1400,PPS,-,-,-,-,V0 K2879 SNA
7.3-13 JC61-00590A BUSH-M-HR R;ML-1400,PPS(RBA313N, CONDUCT K2880 SA
7.3-8 JC61-00595A GUIDE-M-INPUT;ML-1400,PET+GF30%,-,-,-,BL K3960 SNA
7.3-25 JC61-00605A PLATE-P-CLAW;ML-1400,SUS304-CSP,0.1,-,-, H4032 SNA
7.3-1 JC61-01162A FRAME-P-FUSER F2122 SNA
7.3-5 JC61-01172A HOLDER-M-EXIT F/DOWN H4026 SNA
7.3-3 JC61-01177A HOLDER-M-EXIT R H4027 SA
7.3-2 JC63-00615A COVER-M_FUSER Z2149 SNA
JC96-03434A ELA HOU-ENGINE SNA
6003-000196 SCREW-TAPTITE;PWH,+,B,M3,L10,NI SA
6003-000261 SCREW-TAPTITE SNA
6003-000269 SCREW-TAPTITE;BH,+,S,M3,L6,ZPC(Y F1017 SA
6003-000301 SCREW-TAPTITE;BH,+,S,M4,L6,ZPC(YEL),SWRC SNA
7.1-13 JC39-00400A CBF HARNESS-HVPS H1098 SA
7.1-14 JC39-00402A CBF HARNESS-SMPS H1247 SA
7.1-9 JC39-00406A CBF HARNESS-LSU L7002 SA
7.1-4 JC59-00023A UNIT-LSU L7012 SA
SA : Service Available, SNA : Service not Available
Service-BOM Parts List (Model code: ML-1610/XEU)

