Samsung ML-1600 Series - Page 8

΁ΒΣΥΤͽΚΤΥ
Draw#
(Section-No.)
Part Code Description Location SNA
SA : Service Available, SNA : Service not Available
7.1-20 JC61-01170A PLATE-P-CHANNEL P5151 SA
7.1-5 JC63-00621A COVER-M-SMPS S7009 SA
7.1-18 JC63-00631A GROUND-P-HVPS K3232 SNA
7.1-8 JC63-00632A SHIELD-P-ENGINE E2108 SNA
7.1-17 JC63-00722A HEET-HVPS D2132 SA
7.1-15 JC96-01672A ELA UNIT-TERMINAL TR L K3197 SA
7.1-15-1 JC61-00031A SPRING ETC--HV LARGE Z4197 SA
7.1-15-2 JC70-40912A ICT-SHAFT HV LARGE S4027 SA
7.1-3 JC97-02176A MEA UNIT-COVER FRONT Z2409 SA
7.1-3-1 JC63-00616A COVER-M_FRONT(DEVE) Z2146 SNA
7.1-3-2 JC63-00617A TRAY-M-CASSETTE K3955 SNA
7.1-3-3 JC63-00628A TRAY-M-EXTENSION LARGE E5013 SNA
7.1-3-4 JC63-00629A TRAY-M-EXTENSION SMALL E5014 SNA
7.1-2 JC97-02177A MEA UNIT-COVER MAIN T4062 SA
6003-000196 SCREW-TAPTITE;PWH,+,B,M3,L10,NI SA
6107-001169 SPRING-CS;SUS304-WPB,-,PI0.5,D10.25,14.2 SA
JC61-00049A SPRING ETC-TR(KOR) SNA
7.1-2-1 JC61-01155A GUIDE-M-STACKER_RX Z5090 SA
7.1-2-2 JC61-01156A GUIDE-M-SUB STACKER Z5092 SA
7.1-2-3 JC63-00618A COVER-M_TOP Z2168 SNA
7.1-2-4 JC63-00619A COVER-M-MAIN Z2198 SNA
7.1-2-5 JC63-00620A COVER-M-JAM D0027 SA
7.1-2-6 JC64-00184A KEY-M-ONLINE K0045 SNA
7.1-2-7 JC66-00816A LEVER-M-ACTUATOR JAM A1013 SA
7.1-2-8 JC67-00079A LENS-M_LED W3274 SNA
JC99-01614A INA-MATERIAL(A4);ML-1710,SAMSUNG,-,MATER SNA
0105-000107 PAPER-ART;-,W210,-,-,3M,L297 SNA
0105-001032 PAPER-ART;75g,W210,-,WHITE,HANSO SNA
0205-001056 GREASE-GRAPHITE;CRS841,WHT,- SNA
JC99-01861C PAA WOOD-LABEL(XEU) SNA
JB68-00916A LABEL RATING-BLANK;SF-340,SEC,MAT,0.025, SNA
JB75-10029A MEC-RIBBON SNA
JC68-00886A LABEL(P)-REORDER(UK) SNA
JC68-10932B LABEL(P)-BLANK(YELLOW);ML-1710,-,ART,100 SNA
JF68-10532B LABEL(P)-BAR CODE SNA
JC99-01862A PAA-PACKING(SKYLARK) SNA
0203-000007 TAPE-FILAMENT;3M,T0.15,W18,L55M, SNA
0203-001100 TAPE-OPP MASKING;OPP/W75/CLR,T0. SNA
6902-000437 BAG PE;HDPE,T0.015,W900,L800,TRP,8,4PE M SNA
JC69-00739A CUSHION-EPS SET(SKYL) SNA
JC69-00825A BOX(P)-POWER PAD SNA
JC99-01863C INA-ACESSORY(SL_XEU) SNA
6902-000288 BAG PE;LDPE,T0.05,W250,L450,TRP,8,2- SNA
JC46-00249A S/W APPLICATION-DRV SNA
JC68-00421A manual-(card)LBP SVC CARD;ML-6100,SEUK, SNA
JC68-00690A MAN(CARD)-WARRANTY CARD SNA
JF68-10532B LABEL(P)-BAR CODE SNA
7.1-19 3903-000067 CBF-POWER CORD;DT,GB,GP3/YES(A),I(IEC C1 K2903 SA
6801-001014 CARD REGISTRATION;XEU,ENG,MOJO100,L150,W SNA
7.1-16 JC44-00079A HVPS-SKYLARK S7027 SA
7.1-10 JC44-00081A SMPS-(V2C) S7050 SA
JC68-01495A MANUAL-QIG SNA
JC69-00738B BOX(P)-MAIN(ML_1610) SNA
7.1-11 JC92-01640A PBA MAIN-USB_ONLY Z1024 SA
0105-001032 PAPER-ART;75g,W210,-,WHITE,HANSO SNA

