Samsung ML-1600 Series - Page 9

΁ΒΣΥΤͽΚΤΥ
Draw#
(Section-No.)
Part Code Description Location SNA
SA : Service Available, SNA : Service not Available
0202-000008 SOLDER-WIRE;HI-FLO,3.0,-,D3.0,63SN/37PB, SNA
0202-000137 SOLDER-WIRE FLUX;KR-19 RMA SF,-,D0.7,60S SNA
0202-001025 SOLDER-WIRE FLUX;KS-611,-,-,-,spray SNA
0203-001235 TAPE-PAPER;YW-692,T0.15,W5.8,L4000M,- SNA
0203-001236 TAPE-PAPER;YW-4620,T0.12,W6.2,L4000M,- SNA
0204-000469 THINNER;#4662,-,0.795,- SNA
0402-000129 DIODE-RECTIFIER;1N4003,200V,1A,D SA
2005-000168 R-WIRE WOUND,NON;0.22ohm,5%,2W,AA,BK,4x1 DNA
2401-000042 C-AL,100uF,20%,16V,GP,TP,6.3x7,5 SA
2401-001185 C-AL;33uF,20%,35V,GP,TP,5x11,5 SNA
2801-003886 CRYSTAL-UNIT;12MHz,50ppm,28-AAA,16pF,50o SNA
3711-002001 CONNECTOR-HEADER SA
3711-002810 CONNECTOR-HEADER;BOX,9P,1R,2mm,STRAIGHT, SNA
3711-002812 CONNECTOR-HEADER;BOX,11P,1R,2mm,STRAIGHT SNA
3711-003410 CONNECTOR-HEADER;BOX,4P,1R,2mm,STRAIGHT, SNA
3711-003942 CONNECTOR-HEADER;BOX,2P,1R,2mm,STRAIGHT, SA
3711-003969 CONNECTOR-HEADER;BOX,2P,1R,2.5mm,STRAIGH SNA
3722-001101 JACK-USB;4P/2C,8.38mm,AU,IVR,#22 DNA
JB68-00072A LABEL(R)-BAR RIBON;SF-3000,PY,80X91000,T SNA
JB68-00073A LABEL(R)-BAR CODE;SF-3000,PY,38X SNA
JC68-00573A LABEL(R)-BARCODE;ML-4500,PET,T0. SNA
JC94-00812A PHANTOM AU JC92-01640A SNA
0201-001235 ADHESIVE-TS;DEH-390D,RED,400,- SNA
0202-000108 SOLDER-CREAM;RMA-20-21L,-,20~38 ##,62.8S SNA
0401-000116 DIODE-SWITCHING;MMSD914T1,100V,200mA,SOD SNA
0407-000122 DIODE-ARRAY;KDS226,80V,300mA,C2-3,SOT-23 SA
0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT- SA
0501-000457 TR-SMALL SIGNAL;MMBT2222A,NPN,22 SA
0801-000794 IC-CMOS LOGIC;7S08,AND GATE,SOT-25,5P,63 SA
0801-002446 IC-CMOS LOGIC;74LCX14,SCHMITT INVERTER,T SNA
1003-001535 IC-MOTOR DRIVER;A3977SLP,TSSOP,28P,9.6X4 SNA
1103-000152 IC-EEPROM DNA
1105-001264 IC-DRAM;K4S161622,2X512KX16BIT,TSOP,50P, SA
1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, SA
1203-001455 IC-POSI.FIXED REG.;1117,DPAK,3P, SA
1203-002220 IC-POSI.ADJUST REG.;LD1117,DPAK,3P,240MI SA
1203-002233 IC-RESET;XC61F,SOT-23,3P,-,PLASTIC,0.7/1 SNA
1205-002339 IC-CLOCK GENERATOR;CY25811SC,SOIC,8P,150 SA
2007-000067 R-CHIP;15Kohm,1%,1/16W,DA,TP,1608 SA
2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 SA
2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,160 SA
2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 SA
2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 SA
2007-000083 350HIP;3Kohm,5%,1/16W,DA,TP,1608 SA
2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,160 SA
2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,160 SA
2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,160 SA
2007-000096 R-CHIP;30Kohm,5%,1/16W,DA,TP,1608 SA
2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,16 SA
2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608 SA
2007-000116 R-CHIP;120ohm,5%,1/16W,DA,TP,1608 SA
2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,16 SA
2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,160 SA
2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,160 SA
2007-000965 R-CHIP;5.1Kohm,5%,1/16W,DA,TP,16 SA

