Draw#
(Section-No.)
Part Code Description Location SNA
SA : Service Available, SNA : Service not Available
2007-001002 R-CHIP;510ohm,5%,1/10W,TP,1608 SA
2007-001044 R-CHIP;56ohm,5%,1/16W,DA,TP,1608 SNA
2007-001139 R-CHIP SNA
2007-008567 R-CHIP SNA
2011-001011 R-NETWORK;10Kohm,5%,63mW,L,CHIP,8P,TP SNA
2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,TP,1608 SA
2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0, SA
2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R, SA
2203-000384 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,160 SA
2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,T SA
2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP SA
2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160 SA
2203-000783 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,1608 SA
2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP SA
2203-001408 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,1608 SA
2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0 SA
2203-001683 C-CERAMIC,CHIP;0.068nF,5%,50V,NP0,TP,160 SA
2203-002392 C-CERAMIC,CHIP;220nF,+80-20%,50V SA
2203-002398 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,1608 SA
2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608,- SNA
2203-005819 C-CER,CHIP;1000NF,+80-20%,16V,Y5V,TP,160 SNA
3301-001425 CORE-FERRITE BEAD;AB,120ohm,3.2x1.6x1.1m SNA
JC13-00027A IC ASIC-JUPITER4E;S4FD004X,ML-1520,160P, SA
JC41-00258A PCB-MAIN SNA
7.1-1
7.2-0
JC96-03349A ELA UNIT-FRAME_LOWER F2090 SA
0201-001183 ADHESIVE-AA;ARON ALPHA #202F,NTR,100,20G SNA
0203-000007 TAPE-FILAMENT;3M,T0.15,W18,L55M, SNA
0205-000005 GREASE-BEARING;EP56,-,- SNA
0205-001003 GREASE-BEARING;NYOGEL788,DAMPING SNA
0205-001056 GREASE-GRAPHITE;CRS841,WHT,- SNA
0205-001067 GREASE-GRAPHITE;NYOGEL 756G,HYDR SNA
6002-000440 SCREW-TAPPING SA
6003-000196 SCREW-TAPTITE;PWH,+,B,M3,L10,NI SA
7.2-18 6107-001240 SPRING-CS D4084 SNA
7.2-16 JB61-00076A SPRING ETC-TORSION DOC (CC2-F);SCX-1110F Z4274 SA
7.1-12 JC39-00405A CBF HARNESS-MOTOR M2053 SA
7.2-10 JC61-00836A FOOT-FRONT;ML-1750,NBR,D7,-,12,-,- F1011 SA
7.2-1 JC61-01152A FRAME-M-BASE B0080 SNA
7.2-3 JC61-01258A SPRING ETC-TORSION DEVE_L Z4271 SA
7.2-4 JC61-01259A SPRING ETC-TORSION DEVE_R Z4272 SA
7.2-17 JC63-00622A GROUND-P-OPC D4053 SA
7.2-11 JC66-00805A GEAR-RDCN 113/83 G0381 SA
7.2-12 JC66-00806A GEAR-OPC DR 76/38/29 D4047 SA
7.2-13 JC66-00807A GEAR-FUSER DR 63/35 F4086 SA
7.2-14 JC66-00808A GEAR-FEED DR 41 F6076 SA
7.2-15 JC66-00822A LEVER-M-ACTUATOR_EMPTY K3816 SA
7.2-19 JC67-00110A CAP-M-MOTOR A0003 SNA
7.2-8 JC70-00499A ADJUST-M-CASSETTE_L K2014 SA
7.2-7 JC70-00500A ADJUST-M-CASSETTE_R K2015 SA
7.2-5 JC96-03518A ELA UNIT-RX DRIVE D4030 SA
6001-000130 SCREW-MACHINE SA
6003-000269 SCREW-TAPTITE;BH,+,S,M3,L6,ZPC(Y F1017 SA
7.2-5-4 JC31-00020D MOTOR BLOWER-STEP 7.5 P2119 SA
7.2-5-1 JC61-01153A BRACKET-P-GEAR B4025 SNA
