9.2 <
Troubleshooting>
4 Pull the paper straight up and out.
5 Insert the trays back into the printer. Printing automatically
resumes.
In the manual tray
1 Remove the jammed paper from the printer.
2 Open and close the front cover.
3 Load a paper into the manual feeder, then the printer resumes.
Around the toner cartridge
Note
The fuser area is hot. Take care when removing paper from the
printer.
1 Open the front cover and pull the toner cartridge out.
2 Remove the jammed paper by gently pulling it straight out.
3 Replace the toner cartridge and close the front cover. Printing
automatically resumes.
