3.DisassemblyandReassembly
7.ToremovetheMotor,remove4screwsand4
connectors.
8.Removethe2SPURGearafterremovescrew.
NOTE
Whenre-assemblingthese,alignthegrooveofboth
gears.
9.Separatethebracketandmainboardafterremove5
screws.
10.RemovetheSPURGearafterremovescrew.
11.Thereare3Ass’yactuatorshields.Thismanual
describesdisassebmlyprocedureformiddleshield.
Remove2screws(greencolor)fromthefront.
12.Remove2screws(greencolor)fromtherear.
3-28Copyright©1995-2016SAMSUNG.Allrightsreserved.
