3.DisassemblyandReassembly
3.3.Replacingthemaintenanceparts
3.3.1.FuserUnit
CAUTION
Thetemperaturegetsveryhotinthevicinityofthefuser
unit.Whenreplacingit,takenecessaryprecautionsso
youdon’tgetburned.Beforereplacingit,makesurethat
fuserunithascooled.
1.Opentherearcover.Whileopeningtherearcoverata
45°angle,liftuptherightsideoftherearcover,Then
takeofftherearcover.
2.Remove4screws.
3.Liftupthebothlevers.Thentakeoffthefuserunit.
Copyright©1995-2016SAMSUNG.Allrightsreserved.3-5
