Samsung MM-B9 - Front Panel View

GB
4
Front Panel View
1. Function (TUNER/CD/TAPE)
2. REC/Pause
3. Demo
4. On/Standby
5. CD Synchro
6. Headphone Jack Connector
7. AUX
8. CD Repeat
9. Stop
10. DISC Tray
11. Skip or Search
12. Mono/ST
13. CD Door open/close
14. Multi Jog
15. S.Bass Level
16. Sound Mode
17. Volume
18. Power Surround
19. Sleep
20. Push Eject (Cassette Door Open/Close)
