ENGLISH
ACCESSORIES
Depending on the model that you have purchased, you are supplied with
several accessories that can be used in a variety of ways.
1. Coupler, already placed over the motor shaft in the
base of the oven.
Purpose : The coupler rotates the turntable.
2. Roller ring, to be placed in the centre of the oven.
Purpose : The roller ring supports the turntable.
3. Turntable, to be placed on the roller ring with the
centre fitting to the coupler.
Purpose : The turntable serves as the main
cooking surface; it can be easily
removed for cleaning.
DO NOT operate the microwave oven without the roller ring and
turntable.
CONTROL PANEL
1. DEFROST
2. VARIABLE COOKING POWER CONTROL KNOB
3. TIMER KNOB
4. INSTANT REHEAT
1
2
3
4
