ENG - 5
ECHO
You can give an echo effect to the sound from a connected microphone (MIC) by adjusting
the ECHO knob.
If you turn clockwise, the echo effect goes up, and if you turn counter-clockwise, the echo
effect goes down.
VOL
Use the VOL knob to adjust the volume of a connected microphone (MIC).
If you turn clockwise, the volume goes up, and if you turn counter-clockwise, the volume
goes down.
MIC Connect your microphone to the MIC jack.
GROUP
PLAY OUT
Terminals
Use an Audio Cable (not supplied) to connect GROUP PLAY (OUT) terminals on the main
unit to Audio In on an external analog output device.
Be sure to match connector colors.
If the external analog output device has only one Audio In jack, connect either left or
right.
AUX2/
GROUP
PLAY IN
Terminals
Use an Audio Cable (not supplied) to connect AUX2 (IN) terminals on the main unit to
Audio Out on an external analog output device.
Be sure to match connector colors.
If the external analog output device has only one Audio Out jack, connect either left or
right.
Press the (Source) button to select AUX2.
If the product is in AUX2 mode with no playback and no command input for more than
If the product is in AUX2 mode with playback for more than 8 hours and no command
input, the system will turn off.
AUX1
Use an Audio (AUX) Cable (not supplied) to connect AUX1 jack on the main unit to Audio
Out on an external device.
If the product is in AUX1 mode with no playback and no command input for more than
If the product is in AUX1 mode with playback for more than 8 hours and no command
input, the system will turn off.
Power
Connect the power cord to the Power jack and connect the other end of the power cord to
a wall socket to supply electrical power to the Sound Tower.
